Page 187 - Williams BLUE Parts Catalog 16-9064-B

BANZAI RUN (566)
Ball Guide and Ramp Locations
Lower Playfield
Item Part No. Description
1 B-12103 Left Return Frame
2 B-12215 Cannon Ball Guide
3 B-12069 Ball Guide Assembly
4 B-12073 Ball Guide Assembly
5 B-12072 Ball Guide Assembly
6 B-12070 Ball Guide Assembly
7 B-12075 Ball Guide Assembly
8 A-12080 Ball Guide Assembly
9 C-12076 Ball Guide Assembly
10 A-12182 Ball Guide Assembly
11 A-12121 Padded Ball Deflector
12 0-12067 Ball Guide Assembly
13 A-12074 Ball Guide Assembly
14 A-12077 Ball Guide Assembly
15 C-12068 Ball Guide Assembly
16 B-12071 Ball Guide Assembly
17 A-12078 Ball Guide Assembly
18 A-12217 Ball Guide Assembly
19 R-12150 Ramp Assembly
20 A-12102 Right Return Frame
21 8-8623 Ball Guide & Baffle
22 01-3569 Ball Return Runway
23 C-8235 Ball Runway
24 31-1008-566 Screened Bottom Arch
ELECTRONICS GAMES. INC. 3-49
