Page 186 - Williams BLUE Parts Catalog 16-9064-B

CYCLONE (564)
Ball Guide and Ramp Locations
Item Part No. Description
1 Ap 8108-L Left Return Frame
2 C-11982 Hidden Ramp Assembly
(under Spook House)
3 01-8803 Ball Deflector
4 B-11974 Boomerang Loop
5 01-8806 Ball Deflector
6 0-11957 Ferris Wheel Ramp
7 B-12180 Ball Guide Assembly
8 C-11977 Ball Guide Assembly
9 01-8626 Ball Deflector
10 0-11985 Shuttle Ramp
n 0-11978 Ball Guide Assembly
12 8-11976 Ball Guide Assembly
13 0-11979 Ball Guide Assembly
14 R-11986 Comet Ramp-
15 0-11983 Cyclone Ramp
16 A-8108-R Right Return Frame
17 01-3570-2 Ball Guide
18 01-3569 Ball Return Runway
19 01-3571-4 Ball Runway
20 31-1008-564 Screened Bottom Arch
