Page 378 - BallyMidway YELLOW Parts Catalog 16-9147-B

Ball Gate Assemblies - cont'd
Quantity
Per Game BUGS BUNNY (20009) Part Number Description
. _ . _ _.- - - , - ---,-- - -+ - -------+--------+--
A-9465-L
a) 01-6991
b) 12-6565
A-13487
a) 01-8240
b) 01-8600
c) 01-9587
d) 12-6909
e) 5070-06258-00
f) 5647-12073-11
Ball Gate Assembly
Mounting Bracket
Gate Wire
Switch Gate Assembly
Nut Plate
Insulator
Mounting Bracket
Gate Wire
Diode 1N4001 1.0A
Mini Micro Switch
See drawing below.
A-14158
a) 01-8240
b) 01-8600
c) 01-9654-2
d) 12-6951
e) 5070-06258-00
f) 5647-12073-11
Switch Gate Assembly
Nut Plate
Insulator
Mounting Bracket
Gate Wire
Diode 1N4001 1.0A
Mini Micro Switch - -...-' ~ . - - -- -. - -----
4-241 @a!fy/MIDWAY
