(20017)
Ball Guide and Ramp Locations
Item Part Number
Description
1 31~1008-20017 Screened Bottom Arch
2 A-15252-L
Left Ball Return Frame
3 A-15239
Ball Guide Assembly
4 A-15199
Opto Ball Guide Assembly
5 A-15197
Opto Ball Guide Assembly
6 A-15047
Main Ramp Assembly
7 A~15242
Ball Guide Assembly
8 A-15247
Ball Guide Assembly
9
A-15246
Ball Guide Assembly
10 A-14974
Ball Guide Assembly
11 A-15241
Ball Guide Assembly
12 A-15244
Ball Guide Assembly
13 A-15150
Window Ramp Assembly
14 A~15243
BaHGuide Assembly
15 01-10454
Ball Deflector
16 A-15251
Ball Guide Assembly
17 A-15240
Ball Guide Assembly
lB
A-15248
Ball Guide Assembly
19 A-14973
Shooter Ramp Assembly
20 A-15070
Chute Ramp Assembly
(Mtd. under Playfield)
21 A-15250
Ball Guide Assembly
22 A-15249
Ball Guide Assembly
23 A-15245
Ball Guide Assembly
24 A~15252-R
Right Ball Return Frame
Under Bottom Arch:
25 B-8623
Guide
&
Baffle Assembly
26 01-3569--1
Ball Return Runway
27 01-10599
Ball Guide Runway
@af!tt/MIDWAY
3-Sk
