Page 197 - BallyMidway YELLOW Parts Catalog 16-9147-B

(2014)
Ball Guide and Ramp Locations
Item Part No. Description
1 31-1008-2014 Screened Bottom Arch
2 A-81o8-L· Left Ball Return Frame
3 D-13240 Ball Guide Assembly
4 B-13241 Ball Guide Assembly
5 0-13242 Plastic Ramp Assembly
6 B-13465 Ball Guide Assembly
7 A-8108-R· Right Ball Return Frame
Under Bottom Arch:
8 B-8623
9 01-3569-1
10 C-8235
Guide & Bafne Assembly
Ball Return Runway
Ball Runway Assembly
·See p. 3-7 for drawings.
Not shown (See p. 3-24a for drawings):
A·13648 Ball Deflector (2 used)
01-9616 Ball Deflector
@af!tt/MIDWAY
