Page 30 - 1987_BALLY_ASPIRE

BOTIOM PLAYFIELD A$SEMBl Y - PARTS LIST
PART NO. AE52-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
0360-00135-0000 BRKT. : ROLOVER WIRE LEFT
0360-00929-0200 WIRE FORM: ROLLOVER LEFT
20 A360-00215-0100 WIRE ACTUATOR ASSY.: RIGHT
0360-00134-0000 BRKT. : ROLOVER WIRE RIGHT
0369-00903-0100 WIRE FORM: ROLLOVER RIGHT
21 A360-00216-0000 WIRE ACTUATOR ASSY. : RIGHT (3 REQ'D.)
0360-00134-0000 BRKT. : ROLLOVER WIRE RIGHT
0360-00930-0000 WIRE FORM: ROLLOVER RIGHT
22 A360-002JO-OOOO SWITCH & BRACKET ASSY.: SLINGSHOT ASSY. (2 REQID.)
A360-00069-0000 SWITCH ASSY.
23 A360-00239-0000 SWITCH & DIODE ASSY. : SLINGSHOT ASSY. (2 REQ'D.)
A360-00069-0000 SWITCH ASSY.
24 A360-00245-0000 SWITCH~ DIODE & PLATE_ ASSY. (2 REQ I D. )
A360-00058-0000 SWITCH ASSY.
25 A360-00245-0100 SWITCH. DIODE & PLATE ASSY. : W/CAP (3 REQ'D.)
A360-00058-0000 SWITCH ASSY.
26 A365-00035-0000 SWITCH. DIODE & PLATE ASSY. (5 REQ'D.)
A360-00243-0000 SWITCH & DIODE ASSY.
A360-00061-0000 SWITCH ASSY.
27 A365-00035-0100 SWITCH. DIODE & PLATE ASSY. : W/CAP (3 REQ'D.)
A360-00061-0000 SWITCH ASSY.
28 A365-00036-0000 SWITCH, DIODE & PLATE ASSY. (EJECT HOLE) (2 REQ'O.)
A967-00075-0000 SWITCH ASSY.
2 . 1 1
