BOTTOM PLAYFIELD ASSEMBLY - PARTS LISTPART NO. AE52-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AE52-00013-0000 DROP TARGET ASSY. 3 BANK (SEE COMMON ASSY.) (2 REQ'D.)
2 A365-00085-0000 FREE GATE RELAY ASSY. (CLOCKWISE)
3 A365-00086-0000 FREE GATE RELAY ASSY. (COUNTER CLOCKWISE)
4 A967-00053-0000 THUMPER BUMPER ASSY. (SEE COMMON ASSY.) {2 REQ'D.}
5 A967-00059-0000 SLINGSHOT KICKER COIL ASSY. (SEE COM,.,ONASSY.) (2 REQ I D. )
6 AC70-00022-0200 FLIPPER ASSY. SINGLE SWITCH LEFT (SEE COMMON ASSY.) (2 REQ'D.)
7 AC70-00023-0100 FLIPPER ASSY. DOUBLE SWITCH RIGHT (SEE COMMON ASSY.)
8 AC70-00023-0200 FLIPPER ASSY. DOUBLE SWITCH LEFT (SEE CDUMON ASSY.)
9 A369-00017-0000 BALL KJCKBACK ASSY. (SEE COMMON ASSY.)
10 A967-00054-0000 EJECT HOLE ASSY. (SEE COM~10N ASSY.) (2 REQ I D.)
11 A360-0023S-0000 KNOCKER ASSY. (SEE COMMON ASSY.)
12 AE52-00028-0000 TARGET, SWITCH, DIODE & CAP ASSY. RT. (3 REQ I D. )
AE52-00026-0000 TARGET, SWITCH ASSY.
13 AES2-00028-0100 TARGET. SWITCH, DIODE & CAP ASSY. LT. (3 REQ '0.)
AE52-00026-0100 TARGET SWITCH ASSY.
14 AE52-0000S-0000 PLAYFIELD CABLE ASSY.
15 A360-00217-0000 WIRE ACTUATOR ASSY.
0360-00135-0000 BRKT.: ROLLOVER WIRE LEFT
0360-00931-0000 WIRE FORM: BALL RETURN
16 A360-00241-0000 SWITCH & DIODE ASSY.
A360-00055-0000 SWITCH ASSY.: BALL RETURtJ
17 OB42-00102-00XF BRKT. : BOTTOM ARCH (2 REQ'D.)
18 0017-00003-0103 FUSE: MDL 3AG lA 250V SLO-BLO
19 A331-00042-0000 WIRE ACTUATOR ASSY. (3 REQ'D.)
2.10
