DOOR TRIM - RIGHT SIDE
P-5940-31
DOOR TRIM-
LEFT sloe
P-5940-29
26
1 R37
E·l05·245
Resistor, ::4W,5%, 30K
27
5 R12, 36,57,58 ,81
E·l05·230
Resistor , %W,5%, 1K
28
1 R51
E·105·344
Resistor, %W,5%, 750K
29
1 R52
E·105·228
Resistor, %W,5%,9.1 K
30
2 R9,16
E·105·203
Resistor, %W,'5%, 130K
31
1 Rl1
E·105 -248
Resistor, %W,5%, 150K
32
1 R15
E·105·16 1
Resistor, %W,5%, 220K
33
1 R14
E·105-346
Resistor, %W,5%, 1.8K
34
4 R17, 18.39,40
E·105-347
Resistor. %W,5%, 910K
35
1 Rl
E·l05-243
Resistor. %W,5%, 27K
36
1 R68
E·l03-511
Resistor, ::4W,5%, 5100
37
1 R34
E·l05-21l i
Resistor. %W,5%, 2.2
n
38
3 R31 , 88, 89
E·105-303
Resistor , ::4W,5%, 220{l
39
1 R79
E·l05-345
Resistor, ::4W,5%, 7.5K
40
1 R35
E·l05-196
Resistor, ::4W,5%, 1
41
1
R83
E·l05·360
Resistor, ::4W,5%, 11K
42
1 R7
E·l05 ·223
Resistor, %W,5%,8.2K
43
14 C2,5·8, 10,11 , 17,
18,44,47·50
E·586·85
Capacitor, Ceramic , .01 J.I.F. 25V
44
2 C23,35
E·586·130
Capacitor, Ceramic, 47 J.l.F ,16V
45
4 R84·87
E·105·287
Res istor, %W,5%, 2.2K
46
1 R6
E·105 ·342
Resistor, %W,470
47
7 C19, 24, 25, 28,
31,34,42
E·586·90
Capacitor, Electrolyt ic, 1 J.l.F,25V
48
10 C12.13,26.30,33,39 ,
40,41,45,46
E·586·89
Capacitor, Ceramic.. 1 J.l.F,25V
49
2 C9,20
E·586 ·83
Capacitor, Ceramic, 47()pF , 50V
50
1 C32
E·586·120
Capacitor, Ceramic ,68pF
51
1
C21
E·586·68
Capacitor, Ceramic , l00pF
52
1 C15
E·586 ·135
Capacitor, Electrolytic , 10 J.l.F ,16V
53
2
C16,22
E·586·73
Capacitor. Tanta lum. 4.7 J.l.F,25V
54
1 C27
E·586·136
Capacitor, Electrolytic , 1000 J.l.F,16V
55
1 C29
E·586·124
Capacitor, Electrolytic. 470 F,6V
56
2 C3,4
E·586 ·121
Capacitor, Ceram ic. 27pF
57
1 C14
E·586 ·123
Capac itor, Electrolyt ic, 4700 F,25V
58
2 C37.38
E·586·147
Capacitor, Electrolyt ic, 330
"'_F,
50V
59
1 C51
E·586·150
Capacitor, Monolythic. 10pF
60
1 Jl
E·736·18
18 Pin Wafer Connector ~156)
61
1
J2
E·736·10
10 Pin Wafer Connector ~156)
62
1 Used with VRl
E-682·11
Heatsink, 6053
B
63
1 Used with U18
E·682·8
Heatsink 6030B
64
12
P-5399
Test Points
65
1 SW.l
E-658 ·1
P.C.B. Switch
66
3 CA7 .8,10
E·587·15
Diode (lN40Q4)
67
5 CR1, 5,6,9,11
E·587 ·14
Diode (lN4148)
68
1 Yl
E-744·5
Crystal . 3.579
69
1 LEDl
E-679
LED
70
3 01·2,5
E-585·31
Trans istor,2N3904
71
1
Usedwith Ul0
E·712·16
Socket I.C. 16 Pin
72
3 CR2 ·4
E·587·24
Diode, 3A, 50V. min.
73
1 Ul
6808 or 6802 (SEE NOTE 1)
E·620·125 or 128
Microprocessor
74
3 Used with U1, 7,11
E·712·1
Socket, I.C. 40 Pin
75
3 Used with U8, 9, 12
E-712·28
Socket. I.C. 2S Pin
76
3 Used with Ut8, VRl
LSPR·00632·1106
Screw
77
3 Used with U18. VRt
N·00632·2 112
Nut
78
79
J3
E·766·7
Header,
7
Pin
80
2 C36.43
E·5S6·63
Capac itor, 2
J.l.F.
25V
81
2 R69, 70
E·599 -16
Pot . 1K
82
1 C1
E·586·148
Capac itor, Electrolyt ic. 47.
"'_F
83
2 R28 ,54
E·l05·341
Resistor.82K
84
AA Used with U18 , VRl
M·1834
Thermal Compound
85
2 03,4
E·585·23
Transis tor. 2N4403
86
2 R82,48
E·l05·312
Resistor, %W,5%2.4K
JUMPERS - SEE NOTES
DOOR TRIM - TOP
and
BOTTOM
P·5940·30
BACK PLAYFIELO LOCK CHANNEL
P-566
FRONT RAIL LATCH
P·6365·3
M·3'~·3
WASHERS
P·801 ·514
(Not Shown)
4 Req.
FRONT RAI L BRACKET
P·6364 ·6
BUSHING
S·231 ·672
(Not Shown)
3
Req.
WASHER
P·1158·5
WASHER
P·801·107
FRONT RAIL LOCK ASSEMBLY
ASE-2313-7
BUSHING
S·231·695
(Not Shown)
1
Req.
WHEN ORDERING PART. SPECIFY PART NO. AND NAME OF GAME
