MINI-POST &
0
RUBBER ASSEMBLY
@
@
ASE-2836-1
PANEL INSERT PANEL INSERT PANEL INSERT PANEL INSERT
(Plastic Propionate) (Plastic Propionate) (Plastic Propionate) (Plastic Propionate)
C·787·1 Red
C-668-1 Red
C-66?·1 Red
C·666-1 Red
C-787·2 Blue
C·668-2 Blue
C-667·2 Blue
C·666-2 Blue
C-787·3 Yellow
C·668-3 Yellow
C-667-3 Yellow
C-666-3 Yellow
C·787-4 Greeen
C·668·4 Green
C-667-4 Green
C-666-4 Green
POST
POST
C-787-5 White
C·668-5 Wh ite
C-667·5 White
C-666-5 White
(Long)
(Short)
C-787·6 Purple
C-668-6 Purple
C-667·6 Purple
C.666-6 Purple
C-9S2-7
C-9S1-7
C-668-7 Amber
C-G67·7 Amber
C-666-7 Amber
SLING SHOTS
PROTECTIVE SHIELD
M·1787·4
DROP TARGE T ASSEMBLY TARGETS A-3944-XX
ARROW TYPE PLASTIC INSERT
(Plastic Prop ion ate)
C-912-1 Blue C-912-4 Red C-912- 7 Black
C-912-2
Greev
C·912-5 White C-912-8 Amber
C-912·3 Purple C·912·6 Yellow C-912-9 Red (Transl)
THUMPER BUMPER
PROTECTIVE SHIELD
M·1787
l"":::"11""_
RUBBER
R-206-9
MINI·POST
S-2122
BUSHING
HEX SCREW S·231·99
M.1773
(Not Shown)
MINI-POST
ASSEMBLY
AS-2836
RUBBER
COMPONENT PARTS LIST
"'2
1
1 A14
AS-2518-61B
Squawk & Tal k Modu le, Comp lete
2
1 U10
AD558DAC
E-620-171
3
5 Used with U2 thru U6 24 Pin I.C. Socket
E-712
4
2 U7, U11
6821 P.I.A.
E-620-29
5
1 U8
Tms 5200 Speech
E-620-167
7
1 U12
AY3-8812 Sound
E-620· 166
8
1 U6
6810 RAM (See Note 1)
E·620-30
9
1 Ut6
4049 Hex Inverter
E-620 -33
10
2 Ut3, U14
lM3900
E-620 -126
11
1 U15
74LSt4 Schmidt Inverter
e-620- t69
12
t
U17
74LS155
E-620-l68
13
1 U18
TDA 2002 Power Amp
E·620 -127
14
1
VRl
LM323, 5V Regulator
E-7l0
15
1 VR2
7905, -5V Regulator
E-620 ·165
16
19. Rl0, 19,29,42,50,
63-67,71-78,55
Resis tor,
YOW.
10K
E-105,185
17
5 R2-5,B
Resistor,
YOW,
6%, 4.3K
E-l05-238
18
2 R20, 43
Resisto r,
YOW,
5%, 820K
E-105-343
19
2 R2l,44
Resistor ,
YoW,
5%, 390K
E-105-310
20
5 R13, 22, 38, 41, 45
Resistor,
YOW,
200K
E-l05-225
21
4 R23, 24. 46, 61
Resisto r,
YOW,
5% lOOK
E-l0S-226
22
4 R30,53,56,8 0
Resistor,
YOW,
5% 2K
E·l05·237
23
1
R47
Resistor,
YOW,
5%, 2.7K
E-l0S-151
24
7 R25, 26, 27, 32,
49,59,60
Resist or,
YOW,
5% 1M
E-105-285
25
R33
Resistor ,
YoW,
5%, 91 K
E·10S-313
24
_RUBBER
R·206·11
REBOUND
PLATE
P-318-5
WASHER
P·1901
2
Req.
BALL REBOUND ASSEMBLY
ASE-493-6
Name of Game
Target No,
Eight Ball Deluxe
A-3944·22
2X A-3944-27
3X A·3944-28
4X A·3944-29
5X A·3944·30
8 Ball A-3944·32
Fireball II
Fire God A-3944·23
Lighting A-3944·24
Embryon
A-3944·33
Fathom Blue Fish Tail A-3944-34
Green Fish Tail A·3944-35
Blue 3X A-3944-36
4X A-3944-37
5X A-3944-38
Green 3X A-3944-39
4X A-3944-40
5X A-3944-41
Medusa
Red Targets A-3944-42
White Targets A·3944-43
Centaur
1.
A-3944-45
2.
A-3944-46
3. A-3944-47
4. A-3944-48
O. A·3944-49
R. A-3944-50
8.
A-3944-51
S. A-3944-51
Inline A-3944·53
RUBBER NUT
R-412
WHEN ORDERING PART.
SPECIFY PART NO. All) NAME OF GAME
69
