Page 22 - 1981_PARTS_CATALOG_ASPIRE

SPECIAL INDENTED
HEX COLLAR STUD
6-32 Thread
1-11/16" Long - S-2124
1-1/2" Long - S-2124-1
SPECIAL INDENTED
HEX COLLAR STUD
With 6·32 Thread at both ends
1-11/16" Long - 8-2125
1-1/2" Long - 8-2125·1
SCREW
(Used for Speaker Screw &
Thumper Bumper)
M·1786
LONG PRONG TEENUT
8-32 Thread
M·l08·9
LONG PRONG TEENUT
6-32 Thread
M-108-15
A9: AUXILIARY LAMP DRIVER
COMPONENT PARTS LIST
""" --ROD
S·1071-107
ITEM
REFERENCE
QTY. OESIGNA nON
BALLY
PART NO. DESCRIPTION
P·~356 P.C. Board (M·645·461
E·105·173 Resistor 2.2 Meg. Ohm
E-585-29 SCR MCR 106·1
E·715·34 10 Pin Wafer Pin Connector
E·105·237 Resistor 2K Ohm
E·715·39 15 Pin Wafer Pin Connector
E·OO5S6·0065 Capacitor .01 MFD
E·620·84 MV14555B Binary 1 to 4
E·620·85 MV1401JB Dual 0 Flip Flop
E·105·242 Resistor 20K Ohm
BALL GATE ASSEMBLY (Right)
A-1475-9
BAL L GATE ASSEMBLY (Left)
A-1475-10
1
2
3
4
5
6
7
8
9
10
GATE
P·3023
2
R1
Q1 Thru Q12
J2
R9 Thur R20
Jl
Cl
UJ.U2
Ul
12
2
12
BALL GATE BRACKET
P·3022·7
7 R2 Thru RS
WHENI ORDERING PART. SPECIFY PART 10' ..AID lAME OF GAME
GATE
P·3023
BALL GATE BRACKET
P·3022·7
71
