FLIPPER (Left)
A-3739
Blue Lettering
A-3739-2
FLIPPER & SHAFT
ASSEMBLY
ASE-2214-26
FLIPPER ARM
ASSEMBLY
/A . 27 4 7 . 12_:
FLIPPER & SHAFT
ASSEMBLY
ASE-2214-25
FLIPPER &
SHAfT ASSEMBLY
ASE-2214-24
FLIPPER
C-611-5 WHITE
A9: AUXILIARY LAMP DRIVER
COMPONENT PARTS LIST
FLIPPER ARM
ASSEMBLY
A-2747-11
1
1
P-2948-504 P.C.B. (M-645-512)
2
1
Ul
E-620-134 Quad Flip Flop
3
4 U2 Thru U5
E-620-108 BCD to Decimal Decoder
4
28 Ql Thru Q28
E-585-29
S.C.R.
5
28 Rl0 Thru R37
E-l05-237
Resistor, 2K Ohm, ~ W, 5%
6
8 R14, R6-9
E·105-242
Resistor, 20K Ohm, ~ W, 5%
7
1 R5
E-l05-173
Resistor, 2.2M, ~ W, 5%
8
1 Cl
E-586-85
Capacitor •. Oluf. 25 V, ±20%
9
1 Jl
E-736-15
Connector, KK156 15 Pin
10
1
J2
E-736-18
Connector, KK15618 Pin
11
2 J3
E-736-10
Connector, KK15610 Pin
12
2 TP1. TP2
P-5399
Test Point
13
25
M·1777-126 Jumper
WHEN ORDERING PART,
SPECIFY PART NO. AND NAME OF GAME
72
