MOUNTING BRACKET
A'643~7
BALL KICKER
ASSEMBl- Y
A-642-6
SAUCER HOLEi
KICKER ASSEMBLY
SHAFT
AS-428-40
S-181-48 RETAINING
RING
P-631
RETAINING
RING
P-6316-4
(Not Shown)
M-1721:7
CORE PLUG
ASSEMBLY
A-613-30
SPRING
SP-100-230
COIL
UNGER
REFER TO PANEL CHARTS 5-496-38
BRACKET &
SPRING HOOK
ASSEMBLY
A-642-7
TOP MOUNTED BALL KICKER
AS-2694-3
CORE PLUG ASSEMBLY
A-613-89
COIL
REFER TO
PANEL CHARTS
PLUNGER
&
LINK ASSEMBLY
ASE-2586
COMPRESSION SPRING
SP-200-189
KICKER ARM ASSEMBLY
BALL RETURN
A-3545
STRIKER RING
C-838
BASE PLATE ASSEMBLY
A·3546
74
WHEN ORDERING PART.
SPECIFY PART
NO.
AND NAME
OF
GAME
