Page 73 - 1980_BALLY PARTS ASPIRE

SLINGSHOT KICKER
ASE·2593·6 KICKEH ARM
C-972
BASE PLATE
P"7916
CORE .PLUG ASSEMBLY
A-613-115
COMPRESSION SPRING
SP.200-Z12 PLUNGER
S.496·214
.(fJoi/!Jt ®.
NYL.ON 'aUSHING
C-537-12
RETAINING RINGS
P-63Hi-9
COIL
REFER TO
PANEL CHARTS
SLING SHOT KICKER & COl L ASSEMBL V
ASE.·2593-4 COVER PLASTIC
C-1062
PLUNGER & LINK ASSEMBLY
ASE-2586
RETAINING RING
P-6316-5
KICKER ARM __ .....-:::o~ .•.•
ASSEMBLY
A-3459-1
ROLL PIN
P-1637-58
PLUNGER
5-496-198 UNK
P·7:373
SPRING
FREE BALL GATE RELAY ASSEMBLY
AS-2308·21
BALL GATE SHAFT
$-0073.7-0058
REINFORCED RETAINING RING
P-6316-5
HUS & ROLL PIN ASSEMB'L Y
A·3788
PLUNGER &
LINK ASSEMBLY
AS-2586
COMPRE"SSION
~~~~~ L.CORE PLUG &
COIL A'$SE"MBL Y
AS~2597-4
COIL
REFER TO
PANEL 'CHARTS A-j789
'G' RELAY & cal L ASSErv(BL Y
AS:Z656·10
WHEN ORDERING PART. SPECIFY PART' NO. AND NAME OF GAlE
