FRONT
(ABINO
front (abinet,
Assembled
FASTENERS
Order fasteners (nuts,
screws,
washers, etc.)
by
name or description
with
reference to
(a)
part which
fastener secures,
(b) name of game
Front Door Trim
SKYROCKET through* MARINER
Left
_
P·5940-20
Right
_
P·5940·19
Top or Bottom
_ .. _ ....•...
P-6940·21
FIREBALL,
later games*
Left
_
P-5940-29
Right .'
'.'
P·5940·31
Top
or Bottom ..........•
,
P-5940-30
GLASS FRAME, PARTS RELATED TO
Front Rail Lock
Assy.
SKYROCKET through* TWIN WIN ....
AS·2313-5
Bushing,
Longer (3 used)
5·231-672
Shorter
(1 used)
,
,
_
5-231-695
Elastic Stop Nut (4
used)
, ..
M-319-3
Front Rail Bracket
,
P-6364-2
Front Aail
Latch
P-6365-'
Spring Washer
_
, P-1158-5
Washer,
Thicker (1/16 in.) (4 used)
P-801-107
Thinner (1/32
in.)
(4 used)
P-801-514
SKY KINGS,
later games"
AS-2313·7
Same as AS-2313-5, above, except
Front Rail
Bracket
P·6364-6
Front Rail Latch ............•...
P·6365-3
Glass Frame Assy.
SKYROCKET through* TIME ZONE .. AS-2442
Channel
19·3/4 in. long (2 used)
M-1450
40·1/4 in. long (2 used)
M-1450·'
Glass
P-337
Glass Frame Bracket
, .
p · l0n
Moulding
Assvs,
Front
Inside
A-2737-8
Outside
(Top)
A·30BO
Side,
Left
A-3152· 1
Right .................•...
A-3152
Plug Bumper (2 used)
" R-231-12
GLASS FRAME, PARTS RELATED TO
CONTINUED FROM COLUMN 1
NIP·IT
AS-2442-2
Same as AS-2442,
column
one,
except
Moulding
Assy.,
Side, Right
A-3152-2
HI·LO ACE through* TWIN WIN
Same as
in
SKYROCKET,
column
one
SKY KINGS, later games* (NO ASSY. NO.)
Channel (2 used) .•..............
M-1624-7
Glass ........•................
G·409
Mouldings
Front Moulding
AS-2791
Fron t
Moulding Assy
A·3080-14
Side
Left (through WIZARD")
... P-921-73
Right (through WIZARD*)
.. P·921-72
Left (H I-DEAL, Jater games;;') P·921-75
Right (HI-DEAL,
later games*) P·921·74
Glass Trim,
Back
P·565
Insu lator
M-1759
Lock Channel, Back
_
P-56S
Latch Lever
P-6363
See illustration below
Bushing
(latch
Lever)
5-156-410
P.6363
ILLUSTRATED
IN
REDUCED SIZE
*See List of Games, pages 1, 2
WHEN ORDERING PART, SPECifY PART NO. AND NAME OF GAME
209
