Page 211 - 1976_WILLIAMS_ASPIRE

Ball Shooter Assvs.
SKYROCKET throuqh"
CHAMP ' AS·2378·1
As illustrated at left
TWIN WIN
Automatic Ball Shooter,
page 164
SKY KINGS
Same as in SKYROCKET, above
AMIGO through""
KNOCKOUT AS-2378·3
Same as AS·2378-1, above, except
Gu ide Assy. . A·1540-4
Nyliner (added) C-537-22
WIZARD. later games· AS-23784
Same as AS-2378-3, above, except
L4 Knob & Rod Assy A-lOO-7
'ED PA Washer (added) •.............. P-BOl-507
"R7:S-...•....•••.~._---------------,
FRONT CAIINO
Front Cabinet, Assembled
GU IDE ASSY. A·1540·S
SPRING CUP
P·2879
ONE AT EACH END
OF SPRING
TIP R -l084
o o
BALL-SHOOTER PLATE P-1973·291
(Inside of Cabinet)
Bracket
Bushing
Above types of parts
may be ordered by name
with reference to
(A) Name of game,
(8) Specific function of part
Clip
Order by reference to C-271-series,
Inside diameter
Clip, Nylon Tension ............• , ... C-760
"See List of Games, pages 1,2
CONTINUED
ON
NEXT PAGE
WHEN ORDERING PART, SPECIFY PART NO•. AND NAME OF GAME
208
