AUTOMATIC BALL·SHOOTERAS·1566·25
Similar to Ball Return Kicker
on page I 63 with
"racket,
Mounting " .....................• P·3662-6
Coil ........•.........•.......... P·I08·35
SECURED TO P·3662-6
BY 2 SCREW. PARKER KALON,
SWAGE FORM ..•........ SFPR-00832·1106
Coil .........................•... A·2S·950
Core Plug Assy ................•.. , A-613-67
SECURED TO P·3662-6
IN SAME MANNER AS P·I08·35
Guide Ring C·342
Spring Washer ...........•......... P·1158-6
Plunger 8-496·119
Spring, Compression , SP·200-19
Kicker Ann Assy ...........•...... A·)875-6
SECURED TO S-496·119
BY ROLL PLN ................• P·1637.30
SECURED TO P-3662-6
BY
ELASTIC STOP NUT M~319-2
STUD .•........•........... S-1784·2
~---------------------~ 'I
SHOOTER BUTTON
Same as Flipper Button,
page 175, excepting
Switch ..........••••...•. ASW·AIO·12
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
164
