BALL-RETURN KICKER ASSYS.
ALSO SEE BALL-EJECTOR ASSYS., PAGE 159
FIREBALL to * WIZARD ... AS-2694
As illustrated above
1. Base Plate Assy. A-3546
2. Coil ••...........•.... '" A·25-1050
3. Core Plug Assy A·613-67
SECURED TO BASE PLATE
BY 2 SCREWS, SWAGE FORM,
PAN HEAD,
No. '8.x 3/8 in SFS-832-06-P12
4. Cotter Pin M·1536
5. Kicker Arm Assy. A·3545
6. Plunger & Link Assy. ,...... AS-2586
7. Link , P-7373
8. Plunger 5-496·190
9. Roll Pin P-1637-59
10. Retaining Ring , , , . P-6316-5
11. Spring, Compression , , . SP·20()"185
12. Striker Ring , . , . , . , C-838
HI ..DEAL. later games· . , .. , .. , , AS·2694·1
Same as AS·2694, above, except
2., Coil ..•. , , •............. , . AP·25·850
3. Core Plug Assy. , A·613·S9
4. Cotter Pin . , M·1536·'
4A. Fishpaper (added) , P·150
11. Spring, Compression , .•... SP·200-189 "See list of games, pages 1,2
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
