ANTI· TILT COMPONENTS
Front Door
KING REX and earlier games-
AT LOCK END OF DOOR
Tilt Switch & Bracket Assv, AS·982·258
P-126-473
P·126·29
P-150·77
Back -up Plate .
Bracket .
Insulator .
Screw. Parker Kalon, Round Head,
Sheet Metal, Type Z (2 used) .
Switch .
No.4 x 7/8 in.
ASW·A20
Switch Plate P·l 37·5
AT CENTER OF DOOR
Tilt Switch & Bracket Assy AS·982·722
Same as AS·982·25B, above, excepting
Screw, Parker Kalon. Round Head,
Sheet Metal, Type Z (2 used) . . • .. No.4 x 3/4 in.
Switch ASW·A 1
GALAHAD-
Tilt Switch & Bracket Assv, AS-982·754
Same as AS·982·25B. above, excepting
Bracket ..•........................ P·126·185
Switch........................... ASW·A20
CAMELOT through· MARINER
Tilt Switch & Bracket Assy.. .. . . . . .• . . . .. AS-982-762
Same as AS-982· 754, above, excepting
Switch Screw 12 used) MS.540-14-110
Switch Plate,
Flat........................... P·126·154
Spring......................... P·137·5
FIREBALL and later games-
Tilt Switch & Bracket Assv. AS·982-849
Same as AS·982·762, above, excepting
Bracket. . . . . . . . . . . . . . . • . . . . . . . . . .. P-126·660
*See chrono logical list of games , page 6.
Mounting Board
TILT SWITCH & BRACKET ASSY
LITTLE JOE and earlier games· . . . . . . . . . .. AS-982·258
As detai Ied under Front Do or at left
SPACE TIME and later games· AS·982·941
Bracket. . . . . . . . . . . . . . . . . . . . . . . . . .. P·126-29
Switch ASW-Al·25
Swi teh PIate,
Flat ......................•... P·126·154
Spring .... . . . . . . . . . . . . . . . . . . . .. P·137-5
Switch Screw (2 used) MS·540·8-110
Playfield
BRACKET
P-126-408
PLATE
P-126-473
TILT-SWITCH & BRACKET ASSY.
AS-982-460
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
