ANTI·TILT COMPONENTS
Front Cabinet
SOLDER LUG
P·268
SCREW
MS-540-7-110 I NOT INCLUDED IN ASSY. I
SPRING PLATE
P·137·5
BALL TILT ASSYS.
MARINER and earlier games* . . . .. . . .. . .. AS-l588-l
As illustrated above
FIREBALL and later games* . . . . . . .. . . . .. AS-1588-4
Similar to AS-1588-I, above, excepting
Ball (not included in Assy.). . . . . . . . . . .. M-168-S0
Retainer (7-7/8 in. long) P-7751
Switch. . . . . . . . . . . . . . . . . . . . . . . . . . .. ASW-AO-S
Switch Screw (2 used). .. . . . . . . . . . . . .. MS-S40-6-J 10
Terminal. . . . . . . . . . . . . . . . . . . . . . . . .. TT-IO
PLUMB BOB
MARINER and earlier games*
As illustrated at right
FI REBALL and later games*
Similar to illustration at right, excepting
Contact Bracket. . . . . . . . . . . . . . . . . . .. P-7750
Hanger . . . . . . .. P-7783
* See chronolo gica l list of game s, page 6.
CONTIN UED
ON
NEXT PAGE
RETAINER
P·3705·1
BALL
M·168·26
CONTACT
BRACKET
P-275
PLUMB BOB
E-138-3
INCLUDES
THUMB SCREW
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
176
