Page 9 - Bally 1971 Parts Catalog

DESCRIPTION PAGE
Lockout Magnet 13
Lock Plate (Coin Box) . . . . . . . . . . . . . . . . . . . . . . . .. 229
Lubrication Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 5
M
Magnet, Lockout 13
Match Unit 118-127
Metal Post . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 224
Meter: see Total Play Counter
Motor,
Orbit Unit 235
Score Motor Assy. . 83,84
Trip Relay --:-:: 67-74
Mounting Board _ . . . . . . . . . .. 230
Moveable Flipper Assy 206-208
HM" Type I nterlock Relay 48
Mushroom Bumper Assy.
SEE Playfield Charts , 155
N
National Coin Mechanism - 17-26
00-90 Unit 118-127
NETHERLANDS: Coin Mechanism 23
NORWAY: Coin Mechanism - 23
Number Wheel,
Replay Counter 148
Score Counter 145
o
Orbit Unit 234-235
p
Panel Guide. _ 223
Panel Guide Lock 229
Panel Parts 177-225
Panel Support Brackets . . . . . . . . . . . . . . . . . . . . . . .. 229
Plastic Post 224
Plastic Shield: see Playfield Charts 155
Playfield Charts _ 155-176
Playfield Parts - .. 177-225
Play more Post . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 209
Play more Post Bumper
SEE Playfield Charts 155
Plug Bumper .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 229
Plumb Bob Anti-Tilt 151
Plunger Type Kickback Assy. . 217
Post,
Disappearing,
Ball Escape 200
Playmore _ . _ . . . . . .. 209
Metal 224
Plastic 224
Play more 209
Spring 224
R
Rail,
Guide: see Playfield Charts 155
Side: see Playfield Charts. . . . . . . . . . . . . . . . . . . .. 155
Rebound Assy: see Playfield Charts _. 155
Rebound Switch & Bracket Assy 210-214
Relay,
"G" Type 29-34
"G" Type Interlock 35-40
"KK" Type 41-43
"KK" Type Interlock _ 41-43
Trip 51-52
Trip, Motorized ..•........................ 53-75
Trip, Motorized (with Score Motor) 75-82
Replay Button 147
Replay Counter 146,148
Replay Number Wheel Assy : 148
Retainer, Backglass 238
Rollover Bracket 222
Rollover Button: see Playfield Charts _ 155
DESCRIPTION PAGE
Rollover Wire _ 222
ALSO SEE Playfield Charts . . . . . . . . . . . .. 155
Rotor & Shaft, Score Motor 84
Rubber Ring 229
ALSO SEE Playfield Charts . . .. 155
5
Scavenger Button 13
Score Counter 144,145
Score Motor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 84
Score Motor Assy _ _ . 83,84
Score Motor Cam 85-96
Score Motor Gear 84
Score Motor Gear & Shaft . . . . . . . . . . . . . . . . . . . . . .. 84
Score Motor Rotor & Shaft. . . . . . . . . . . . . . . . . . . . .. 84
Score Motor Stator . . . . . . . . . . . . . . . . . . . . . .. 84
Score Motor Switch 85-96
Score Motor-Trip Relay 75-82
Score Motor-Trip Relay Cam _ .. 82
Score Motor-Trip Relay Switch. . . . . . . . . . . . . . . . . .. 80
Selector Assy., Target 219
Shield,
Glass Frame .. . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 229
Lamp _ _ . . . . . .. 226
Plastic: see Playfield Charts 166
Shooter Gauge: see Playfield Charts 155
Side Rail: see Playfield Charts. . . . . . . . . . . . . . . . . .. 155
Single Step Reset Stepping Unit 138-142
Slide, Coin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 27
Slingshot Kicker Assy. . 210-215
Slug Rejector 17-26
Slug Rejector Mount Assy 11,13
Socket, Lamp 27,226
Sound Components. . . . . . . . . . . . . . . . . . . . . . . . . .. 153
Sounder Assy. . . . . . . . . . . . . . . . . . . . . .. 153
Spacer, Coin Guide _ 11,13 ;17-16
Spring Post 224
Spinner Unit 131,136,137
Spring, Switch Stack _ . . . . . . . . . . . . . . . . . . . .. 97
Standard Bumper 179
Stator, Score Motor _ 84
Stepping Unit,
Continuous 113-117
Continuous (00-90) (Match) 118-127
Full Reset __ .. _ 128-135
Single Step Reset 138-142
Stop Bracket, Glass Frame 229
SWEDEN: Coin Mechanism 24
Swing Type Free Ball Gate
SEE Playfield Charts 155
Switch,
Anti-Tilt 151,152
Coin __ 11,13
"G" Type Relay. . . . . . . . . . . . . . . . . . . . . . . . .. 30-34
"G" Type Interlock Relay. . . . . . . . . . . . . . . . .. 36-40
Miscellaneous l01-112
Rebound 210-214
Score Motor. . . . . . . . . . . . . . . . . . . . . . . . . . . .. 85-96
Score Motor-Trip Relay 80
Target: see Playfield Charts 155
Trip Relay 54-66
Switch Actuators .. _ _ . . . . . . . . . . . . . . . .. 98,99
Switch & Bracket Assy.,
Anti-Tilt 151,152
Flipper-Zipper 210-214
Rebound 210-214
Slingshot Kicker 210-214
Target: see Playfield Chart. . . . . . . . . . . . . . . . . . .. 155
Thumper Bumper 181-185
SWITZERLAND: Coin Mechanism 24
Switch Stack Spring. . . . . . . . . . . . . . . . . . . . . . . . . . .. 97
Swivel Type Free Ball Gate 194-199
3
T
Target Kicker Assy 218
Target Selector Assy. _ . . . . . . . . . . . . . . . . . . . . . . . .. 219
