DESCRIPTION PAGE
Target Switch Assy.
SEE Playfield Charts 155
Thumper Bumper 180-185
Tilt Assy.,
Ball Type . . . . . .. 151
Pumb Bob Type _ .. 151
Tilt Switch & Bracket Assy. . _. . . . .. 152
Top Arch: see Playfield Charts __ 155
Total Play Counter _. . . . . . . . . .. 230
TRAIL DRIVE Animation Unit _ 236,237
Transformer . . . . . . . . . . . . . . . . . . .. 230
Trim, Front Door . . .. 228
Trip Relay _. _ 51,52
Trip Relay Motor _ .. _. 67-74
Trip Relay. Motorized . _ _ 53-74
Trip Relay Reset Cam 67-74
Trip Relay-Score Motor
SEE Score Motor -Trip Relay
Trip Relay Switch _ . _ 54-66
Trough, Ball. 220-221
U
UNITED KINGDOM: Coin Mechanism __ 25
UNITED STATES: Coin Mechanism .. . _ , 26
DESCRIPTION PACE
V
VENEZUELA: Coin Mechanism _ 26
W
Wheel, Number,
Replay _ . _ . . . . . . . . . . . . . . . . . . . . . . . . . . .. 148
Score _ 145
Wire ,
Ball Gate: see Playfield Charts 155
Ball Guide: see Playfield Charts _. . . . . . . .. 155
Coin Switch _ 11,13
Rollover: see Playfield Charts __ _. .. 155
Y
YUGOSLAVIA: Coin Mechanism _ , 26
Z
ZAMBIA : Coin Mechanism _ 26
