"G" TYPE INTERLOCK RELAYS
KEY TO SWITCH LISTING
Switches are listed below in numerical order, commencing with
Switch Plate end of each switch-stack.
When 2 switch-stacks are used, stack nearest to Relay
Mounting Board is Stack A. Second stack is Stack B.
VAMPIRE
GAME OVER
(Mounting Board) AS -2651 -1
As Illustrated, page 35, with
Switch,
1st ... ........•. ... ASW·R3 -1
2nd,3rd ASW·R2 -1
4th ASW-Rl -3'7
Swit ch Plate P -137-14
Switch Screw MS -540-25 -110
2ND COIN
(Back Cabinet Insert) ... . AS-2651 -2
Same as AS-2651-1, above excepting
Switch,
1st, 2nd. . . . . . . . . . . .. ASW-R3 -1
3rd ASW -R2 -1
4th ASW·Rl -3
FIRECRACKER
GAME OVER AS -2651
Used in 18 Relay Bank,
Mounting Board
Same as AS-2651 -1, above, excepting
Switch,
1st ASW-R3 -1
2nd, 3rd, 4th ASW·R2 -1
5th ASW-R1-3 -7
Switch Screw MS-540-32-110
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
