Page 37 - Bally 1971 Parts Catalog

"G" TYPE INTERLOCK RELAYS
Other "G" Type Relays shown on page 29
SPRING RETAINER
BRACKET
P-7491
SPRING
SEE TABLE BELOW
TRIP RELAY
ARMATURE GROMMET
TRIP RELAY
FRAME
P-7473
SECURED BY
LOCKSCREW (2)
LS-632-4-510
AND
PLAIN WASHER (2)
PW-6-10
INTERLOCK RELAY
FRAME
P-7471
PART NUMBERS
MARKED ON WRAPPER
SECURED BY
8-32 x 3/8 IN. LONG
WASHER HEAD
HEXAGON SEM SCREW
(BRASS)
AND
BRASS WASHER P-801-149
LATCH RELAY
ARMATURE ASSY.
A-3518
SWITCH ACTUATOR
SEE PAGE 99
SEPARATOR
SEE NOTE BELOW
SWITCH BASE SEPARATORS
Switch Base Separators, used only as required, are 9/16 in.
by 5/16 in. with 2 holes for switch screw.
1/32 in. thick (approximately) 5MB-1
1/16 in. thick (approximately) 5MB-2
SPRING TABLE
COLOR PART NO.
Natural (not dyed) SP-199-28
Red SP-199-29
WHEN ORDERING PART I SPECIFY PART NO. AND NAME OF GAME
