Page 34 - Bally 1971 Parts Catalog

"G" TYPE RELAYS
KEY TO SWITCH LISTING
Switches are listed below in numerical order, commencing with
Switch Plate end of each switch-stack.
When 2 switch-stacks are used, stack nearest to Relay
Mounting Board is Stack A. Second stack is Stack B.
FIRECRACKER FIRECRACKER
5 Bank (Back Cabinet Insert)
10 POINT
Eyelet (2 used) M-122-19
Grommet (2 used) .. R-III -29
Relay Frame
Switch,
Stack A
1st, 2nd, 3rd ASW-Rl X-I
4th ASW-RI-3
Switch Screw MS -540-25 -110
Stack B . . . . . . . . . . .. ASW-Rl-l
Switch Screw .. ... MS-540-10 -110
100 POINT
P -7472-2
Same as 10 POINT, excepting
Switch,
Stack A
1st ASW-Rl-4
2nd,3rd ASW·Rl X-I
4th ASW-RI-3
Switch Screw MS -540-25-110
Stack B
1st ASvy-R2-1
2nd ASW-Rl-1
Switch Screw MS-540-14-110
1000 POINT
Same as 10 POINT, excepting
Switch,
Stack A
1st, 2nd, 3rd ASW-Rl X-I
4th ASW -RI-3
Switch Screw MS -540-25-110
Stack B
1st ASW-R1X-l
2nd ASW-Rl-1
Switch Screw MS-540-14-110
NO.1 SCORE RESET
Relay Frame P-7472-1
Switch,
Stack A
1st, 2nd , 3rd, 4th .. ASW-Rl X-I
Switch Screw .. .. MS -540-25-110
Stack B: same asStack A
NO.2 SCORE RESET
Same as NO.1 SCORE RESET
Switch Plate (lOused) ... P-137 -14
5 Bank (Playfield Panel)
LEFT RED THUMPER BUMPER
Relay Frame
Switch,
1st ASW -RI-4
2nd " ASW-Rl X -I
3rd ASW -Rl-1
Switch Screw MS-540-20-110
RIGHT RED THUMPER BUMPER
Saine as LEFT RED THUMPER BU~~PER
BLUE THUMPER BUMPER
Same as LEFT RED THUMPER BUMPER
ON KICKER
Relay Frame P-7472-1
P-7472-1
Switch,
lst,2nd ASW -RI-3
Switch Screw MS-540 -14-110
POST
Relay Frame . . . . . . . .. P-7472-1
SWitch,
1st ASW -R2-1
2nd ASW -RI-3 -7
3rd ASW -Rl-1
Switch Screw MS-540-20-110
Switch Plate (5 used) P-137-14
FIRECRACKER
9 Bank (Mounting Board)
DELAY
Relay Frame P-7472-1
Switch,
1st, 2nd ASW-R2 -1
3rd,4th ASW-Rl-4
Switch Screw MS-540-25 -110
SPIN PULSE
Relay Frame. . . . . . . .. P-7472-1
Switch,
t st ASW -Rl-4
2nd, 3rd ASW-R 1X -I
4th ASW-Rl-1
Switch Screw MS-540 -25-110
EJECT
Relay Frame P-7472-1
Switch,
Stack A
1st ASW-R2 -1
2nd ,3rd,4th ASW'RI-3
Switch Screw MS-540 -25-110
Stack B: same a 'sStack A
ALTERNATOR
Relay Frame P-7472-1
Switch,
1st, 2nd. 3rd ASW-R3-1
Switch Screw MS-540-20-110
3000 POINT
Relay Frame
Switch,
1st _ ASW-R2-1
2nd,3rd ASW-RI -3
4th ASW-Rl-l
Switch Screw MS-540 -25-110
EXTRA BALL TARGET
Relay Frame. . . . . . . .. P-7472-1
Switch,
lst,2nd ASW-Rl-4
3rd ASW·Rl X-I
4th ASW -Al - l
Switch Screw MS-540 -25-110
BONUS ADVANCE
Relay Frame. . . . . . . .. P-7472-1
Switch,
lst ASW-Rl-4
2nd ASW-Rl X -I
P-7472-1
3rd ASW-Rl-1
Switch Screw MS-540-20-110
GATE LIGHT
Relay Frame P-7472-1
Switch,
1st, 2nd ASW -RI -3
3rd ASW-RI-4
Switch Screw MS-540 -20-110
GATE TARGET
Relay Frame P-7472-1
Switch,
1st ,2nd ASW'RI-4
3rd ASW -Rl-1
Switch Screw MS-540 -20-110
Switch Plate (10 used) '" P-137-14
CONTINUED
ON
NEXT PAGE
WHEN ORDERING PART, SPECifY PART NO. AND NAME Of GAME
30
