Page 32 - Bally 1971 Parts Catalog

CIRCUIT CONTROL COMPONENTS
Cam Followers ' ', 97
FUSES, FUSE BLOCK: SEE PAGE 226
Relays, '~G" Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29'·40
Relays, "KK" Type 41·47
Relays, "M" Type ' ,48·50
Relays, Trip. . . . . . . . . .'. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51·82
.. Relays, Trip, Motorized. . . . '. . . . . . . . . . . . . . . . . . . .'. . . . . . . 53·82
Relays, Trip (with Score Motor Assy.) ,~ 75·82
\
RESISTOR (FRONT DOOR): E·105·6 '
Score Motor Assys.. . . . '. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83, 84
Score Motor Cams and Switches. . . . . . . . . . . . . . . . . . . . . . • 85·96 '
Spinner Unit Assy•........................ ~ 136·137
Stepping Units, Continuous. . . . . . . . . . . . . . . . . . . . . . . . . . 113·117
Stepping Units, Continuous (0-9) (00·90). . . . . ... ~. . . ... 118·127
" Stepping Units, Full Reset. . . . . . . . . . . . . . . . . . . . . . . . . . .128·137
Stepping Units, Single Step Reset 138·142
Switch Actuators '. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98·100
, .
Switches ' 101·112
Switch Stack Springs 97
TRANSfORMER: E·122·95
