Page 20 - Bally 1971 Parts Catalog

ALTERNATOR UNIT AS·1900·122
3 (DINS PER PLA Y
I () 0 D
~----------------__,STOP PLATE
ON OPPOSITE SIDE OF ASSY.
P-5222-1
SCREWS
Order screws by name or description with reference to
(a) AS ·1900·122,
(b) Part screw secures
(})NOT VISIBLE AT POSITION 1 ARE:
(a) Between Ratchet and Base Plate:
Bushing S·231 ·730
(b) Back of Base Plate:
Washer, Plain.... .. . PW ·8 ·10
Elastic Stop Nut. . . . . . . .. M·319 ·6
(j)PIUnger'
@Drive Pawl'
@ShoUlder St ud
S496181'
C ·4357'
S ·2028
@SWitCh Plate (Spring) ..
@SWitCh .
P-137 -5
@Base Plate A ssy
@HalfPin W a sher
@Spring, Ext ension
@Spring, Ext ension .
@HOld Pawl
A -221428 CID Rocker Arm C -703 -1
@HairPin Washer ' M ·254 -1
Also use with Hold Pawl
M 254
SP -100-121
S p -100·258
ASWM·100-1 C 708
@core Plug Assy . . . . . . . . . . . .. A 613 -78
(1) Coil E -184 ·206
®ROII Pin' P ·1637-43'
@R a tchet C 704-1
'Starred components constitute Drive Pawl Assy.
AS·2293-6 and may be purchased separately or
as Assy. AS·2293-6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
16
