NOTE A
Coin Switch
&
Rejector Mounting Assy. AS-277-137.
illustrated on page 13, is used only with
Single Coin Chute,
BIG VALLEY and later
games*.
Other Coin Switch
&
Rejector Mounting Assys. are detailed
in NOTE
A,
page 12.
NOTE B
When ordering complete Assy .. specify
(a) Coin. as stated in NOTE C.
(b) Coin Guide. as stated in NOTE
D.
(c) Coin Guide Spacer. NOTE
D.
NOTE C
Coin Switch is either
E-I 08-92
or
E-lmV)8.
depending
on weight of coin.
If
not sure
of
correct part
number,
order Coin Switch
by
name with reference to (a)
coin denomination.
(b)
name of
game.
NOTE 0
To determine correct part number
of Coin
Guide and Coin
Guide Spacer refer to international
Coin Mechanism Data,
commencing on page
23.
SCREWS
Order screws by name or description with reference to
(a) AS-277-137,
(b) part screw secures.
*See chronological list of games, page 6.
