Page 137 - Bally 1971 Parts Catalog

SLING·SHOT KICKER & COIL ASSY. AS·2593
Introduced in FIRECRACKER*
ALSO SEE PAGES 210, 211
G
®
CD
1 2 0
®
@
@
o Core Plug & Coil Assy
o
CD
AS -2587
Coil : par t numb e r m a rked on w rapper
... .. P -l08 Coil B rack e t
SECURED TO MOUNTING BRACKET
BY MEANS OF
Lockwa sher, S plit (2) No.6
Nut (2) N -632-2112
Scr ew (Phillips) (2) MS -632 -5-112
Core PI ug Assy A -613 -88
(INCLUDES MOUNTING BRACKET)
Ki cker Arm Assy A -3459
Plunger & Link Assv , .. AS ·2586
Link P -7373
P lung e r .. S-496-190
Roll P in . P -1637 -59
Re tain ing Ring P·6316 -5
Spring , Cornor cssi on SP -200 -180
* See chronological list of games, page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
