COSMOS
DESCRIPTION
PART NO.
PLAYER ADVANCE
Coil. . . . . . . . . . . . . .. C ·7800 -333
Frame
A·604L ·5
MATCH
Coil, Frame same as BALL RETURN
PLAYER RESET
Coil, Frame same as BALL RETURN
SERIES
Coil. . . . . . . . . . . . . .. C·7800 ·351
Frame. . . . . . . . . . . .. A·604LD ·5
RED MUSHROOM BUMPER
Coil
C·7800·3316
Frame. . . . . . . . . . . .. A ·604LD ·5
YELLOW MUSHROOM BUMPER
Coil. . . . . . . . . . . . . .. C ·7800·3316
Frame. . . . . . . . . . . .. A ·604LD ·5
RE·ENTRY
Coil, Frame same as BALL RETURN
BLAST·OFF
Coil, Frame same as BALL RETURN
Relay Fastener
Order nut, screw , etc .
by name or description
with reference to
(a) Name of game ,
(b) Name of Relay,
(c) Part which fastener secures
Relay Switch
Order by name with reference to
(a) Name of game,
(b) Name of Relay,
(c) LEFT or RIGHT ,
when Relay used 2 switches ,
to indicate re'ative position
view from lug side
Relay. Trip, Motorized
Coil
8.
Switch Assy,
AS ·2408 ·5
As illustrated ,page 101, excepting
Armature Any .
(12 used)
A ·261 ·11
(NOT USED) .
A -261 ·12
Bracket & Stud Assv .
See Relay Bank AS ·2530 below
Bracket, Relay
(NOT USED) .
P·6822
(12 used)
P ·6822 ·1
Coil (12 used)
E ·184 ·155
Fasteners
Order nuts , screw , washers
by name or description
with reference to
(a) AS-2408 ·5,
(b) Part which fastener secures
Latch Plate Assy.
(12 used)
A-261 -13
(NOT USED)
A·261·15
DESCRIPTION
PART NO.
DESCRIPTION
PART NO.
Relay Bank
AS ·2530
Bracket
&
Stud Assy
A 3120 ·2
Cam Follower
See page 109
Screws
Order by name or description
with reference to
(a) AS ·2530
(b) Part which screw secures
Spring, Switch Stack
See page 109
Switch
See pages 107, 108
Switch Actuator
See page 110
Reset Mechanism
AS ·2409 -6
As illustrated, page 102, excepting
Cam & Hub Assy
A·800 ·140
Cam, Reset
(12 used)
C·706
(NOT USED),
C-706 ·1
(NOT USED)
C·706 ·2
Clutch and related parts
(NOT USED)
End Plate Assy .,
Remote from Motor ... A·3095 ·1
Roll Pin
(NOT USED)
P·1637 ·17
(2 used, Main Shaft)
P ·1637 ·57
Screws
Order by name or description
wi
th
reference to
(a) AS·2409 ·6
(b) Part screw Secures
Shaft, Cam
5·1961 -12
Tie Rod
5·1962 ·12
Replay Counter
Same as in THE WIGGLER, page 47
Rollover Buttons, parts related to
Bushing
5·1559 ·1
Button,
Large
C ·387 ·5
Small
C ·387 6
Push ·onFastener
M·298 ·9
Switch
SW · l00 ·497
Washer
Black
P·801 ·258
Cadmium plated
p·801 ·125
Score Motor Assy•.. .......
AS ·2380 ·35
As illustrated, page 105, 106 with
Cam Assy
AS·975 ·132
Cam 1
P ·1365 ·537
Cam 2
P-1365 -577
Cam 3
P·1365·564
Cam 4
P-1365 -565
Cam 5
P·1365 ·566
Cam 6
P·1365 ·567
Cam 7
P ·1365 -56B
Cam 8
P ·1365·569
Cam 9
P -1365 -570
Cam 10
P 1365 ·546
Cam 11
P-1365 ·580
Hexagon Shaft
5-1947
Retaining Ring (2) .
P·2891 ·8
Spacer (10)
5·1949
Spring, Comprenion
SP -200 ·31
Screws
Order by name or description
with reference to
(a) AS-2380 -35,
(b) Part which screw secures
Switch & Bracket Any
AS·982 -666
Bracket
P·126 ·537
Cam Follower: see page 109
Screw
Order by name or deocrlptlon
with
reference to
(a) AS-982 -666 ,
(b) Part which screw secures
Spring, Switch Stack
See page 109
Switch : .ee pages 107, 108
Switch Actuator : see page 110
Switch Plate (11)
P-137 -5
Shooter Gauge, Ball
P 6359 -6
Side Rails,
Left
P ·6360 30
Right
A·2900 ·15
Slingshot Kicker, parts related to
Coil Assy. (2 used)
AS ·156610
As illustrated. page 135 •• xcepting
Coil
E-184 -243
Screws (4 used) ,
Parker Kalon ,
Swage Form
No . 8 -32 x
3/8
Coil Assy. (1 used)
AS ·1566 ·11
Same as AS-1566 · '0 above. excepting
Kicker Arm Assy
A 1875 ·4
Switch
&
Bracket Any.
See Rebound Switch Assy. above
Stepping Unit, Continuous
Match
(0-91
Unit
AS 827 ·317
Same as in MINI ·ZAG. page 61
Stepping Unit, Full RltS8t
Ball Count Unit
AS-827 ·287
Same as in DOG IES, page 52
Coin Unit
AS ·827 ·276
Same as in DOGI ES, page 52
Player Up Unit
AS 827 ·275
Same as in DOGI ES, page 52
Switch
8.
Bracket Assy.
Flipper Zipper
As described, page 140
Thumper Bumper. parts related to
A. illu.trated and d.'crtbed . page 131
COSMOS (Add-A-Ball)
Same as COSMOS, modified with
Added Balls Kit
K -313·7
IN BACK CABINET INSERT
Cover, Replay Window .. . M ·1383 -6
ON MOUNTING BOARD
Added Balls Relay
E 146 695
("KK" Type, illustrated page 103)
Coil
C·7800 -3310
Frame
A-604L -5
Added Bans Cable
E ·556 ·297
Connector
E -139 ·10
SHIPPED IN ENVELOPE
Add·A·Ball Cards
Connector
E-139 ·4
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
