SPECIFIC --PARTS DATA
Listed chronologically by games
COSMOS
DESCRIPTION
PART NO.
Ball Ejector Unit
Playfield Action.
. . . . . .. AS-428-26
As illustrated. page 136. EXCEPTI NG
Bracket Any .• Mounting.
A·643-7
Coil ... . . . . . . . . . . . .. E-184-207
Spring. EKten.ion.
(Instead of SP·199-11) SP-199-25
Ball Gate Assy.
See Gate
Ball Kicker
See Ball Ejector Unit
Ball Return Guide. . . . . . .. P-6346·1
Ball Return Kicker
See Ball Ejector Unit
Ball Return Trough Assy. .. A-2896-3
Ball Return Unit
S~" Ball Ejector Unit
Ball Shooter Gauge .. . . . .. P-6359-6
Coin Unit
Se~Stepping Unit, Full R_t
Counter
Ball
5••••Stepping Unit, Full Reset
Bonus
Same a. Count.r, Super Seor.
CAPERSVILLE.
page 43
Fuel Pod
See Counter. Bonul,
Replay
Same a. in THE WIGGLER. page 47
Score
Same as in CAPERSVILLE. page 43
Total Play
E-130-10
Flipper
See Flipper·Zipper below
Flipper & Pin ANY.
Left _
_ _ AS-2214-11
Same as in SURFERS. page 49
Right .. _
__. . .. AS-2214-12
Same as in SURFERS. page 49
Flipper Zipper
S.IIIU!
as
III
ROCKET III.
p.Jqe
45
IMPORTANT:
ALSO SEE PAGE 141
ALSO SEE:
Switch
&
Bracket A5SY:
Flipper Zipper
Free Ball Gate
Se••Gate
Gate
Ball. . . . . . . . . . . . . . . . .. AS-1315·4
Free Ball
Above panel
Push Fauen"r . . . . . .
M-1314-1
W"e '" . . . . . . . . . .. M-1335·1
Below panel
AS-1587-61
As illuUrated, page 146. EXCEPTING
Base Plate. . . . . . . . .. P·3691·18
Bracket. Switch. . . . .. P-126-559
DESCRIPTION
PART NO.
DESCRIPTION
PART NO.
FASTENER between Plunger
and Lever Arm Assy.
See Roll Pin below
Lever Arm Assy
A-1889-8
Plunger. . . . . . . . . . .. 5-496-167
Retaining Ring
P-6316-5
Roll Pin
_
P-1637-1
Screws: order by name
with reference to AS-1587-61.
part which screw secures
Set Screw
_. M-1369
Switch
SW-ll0-123
Gauge, Ball Shooter. . . . . .. P-6359-6
Guide. Ball Return _. _. . . .. P-6346-1
Kicker
See Ball Ejector Unit
See Slingshot Kicker
Lockdown, Play field Panel..
P-67845
Match Unit
See Stepping Unit, Continuous
Meter
S"e Counter, Total Play
Moveable Flipper
See Flipper Zipper
Orbit Unit
_. __
As illustrated. page 143
AS-2380 34
Plastic Shield (Set) _. _. . . .. M-1330-51
Player Up Unit
See Stepping Unit. Full Reset
Playfield Panel Latch Rail
See Side Rail
Playfield Panel Lockdown _.. P-6784-5
Rails
See Side Rails
Rebound Switch A5SY.
5 used·
AS-982-509
7 use
d"
AS-982-561
Both illustrated. page 135
• U.ed with
Rebound s,
Sling5hot Kickers
Relay Interlock
(illustrated. page 103)
See Relay, "KK" Type,
8 Bank
Relay, "KK" Type
(illustrated. page 103)
Single Relay
LEFT THUMPER BUMPER
Coil
C-7800-334-0
Frame
A-604A-5
LOWER THUMPER BUMPER
Same as LEFT THUMPER BUMPER
TOP THUMPER BUMPER
Same as LEFT THUMPER BUMPER
No.1 RESET
Coil
C-7800-331-0
Frame
A-604L-5
No.2 RESET
Same as No.1 RESET
No.3 RESET
Coil
C-7800-331
Frame
A-604L·5
5 Bank
SHOOT AGAIN
Coil
C-7800-331
Frame
A-604L'5
FREE BALL
Coil
C-7BOO-341
Frame
A-604LD-5
FREE BALL ROLLOVER BUTTON
Coil. Frame same as FREE BALL
PLANETS
Coil
C-7800-351
Frame. . . . . . . . . . . .. A-604LD-5
TOP REBOUND
Coil
C-7800-3316
Frame. . . . . . . . . . . .. A-604LD-5
8 Bank
COIN (Interlock Relay)
Coil
Latch. . . . . . . . . . .. C-7800·331
Trip ..•..........
C-7800·334
Frame
_. . . .. Z-1154·3
GAME OVER (Interlock R"lay)
Coils. Frame same as COl N
CLOSE FLIPPER
Coil
C-7BOO-3312
Frame _. . . . . . . . . . .. A-604L·5
100 POINT
Coil. . . . . . . . . . . . . .. C-7800-333
Frame. . . . . . . . . . . .. A-604LDP·5
10 POINT
Coil. Frame same as 100 POINT
1 POINT
Coil. Frame same as 100 POI NT
50 POINT
Coil. . . . . . . . . . . . . .. C-7800'331
Frame. . . . . . . . . . . .. A-604L·5
START
Coil. Frame same as 50 POINT
15 Bank
1ST COIN CHUTE
Coil. . . . . . . . . . • . . .• C-7800-331
Frame. . . . . . . . . . . .. A-604LP-5
2ND COIN CHUTE
Coil. Frame same al 1ST COIN CHUTE
3RD COIN CHUTE
Coil, Frame same .s 1ST cal N CHUTE
MULTI-PLAY
Coil. Frame same as 1ST COIN CHUTE
ANTI·CHEAT
Coil. . . . . . . . . . . . . .. C-7800-3312
Frame. . . . . . . . . . . .. A-604L·5
HOLD
Coil. . . . . . . . . . . . . .. C-7BOO-332
Frame. . . . . . . . . . . .. A-604L-5
BALL RETURN
Coil. . . . . . . . . . . . . .. C-7BOO·331
Frame. . . . . . . . . . . .• A·604L·5
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
63
