SPECIFIC PARTS DATA
Listed chronologically by games:
MINI-ZAG
DESCRIPTION
PART NO.
BALL RETURN
Coil
C-7800 -331
Frame
_ . __ _ A-604L-5
MATCH
Coil
.....•....
C·7800·334
Frame
A-604L -5
CLOSE FLIPPER
Coil. Frame same as ANTI-CHEAT
ZAGGER LANE
Coil, Frame same as GROOVY
50 POINT
Coil, Frame same a. BALL RETURN
WHITE MUSHROOM BUMPER
Coil, Frame same as GROOVY
YELLOW MUSHROOM BUMPER
Coil, Frame same a. GROOVY
BALL COUNT
Coil, Frame same as ANTI-CHEAT
Relay f astene,
Order nut, screw. ere . by name or
descr iption with reference to
(a) Name of game .
(b) Name of Relay,
(c) Part which fastener secures
Relay Switch
Order by name with reference to
(a) Name of game .
(b) Narne of Relay .
(c) When relay uses 2 switche s,
indicate relative position,
viewed from lUll side
by reference to
LEFT or RIGHT
Replay Counter
Same a. in THE WIGGLER.
page 47
Rollover Bunon,
par15 related to
Bu.hing . _
S·1559 ·1
Button . _ . _
C·387 ·5
Push ·on Fanener
M·298 ·2
Switch .... ... ...•..
, .. SW -l00 -497
Wa.her.
Black
P·801 ·258
Cadmium plated
P·801 ·125
Score Motor Assy
AS 2380 ·29
As illu.trated,
page. 105.106.
with
Cam Assy
AS 975 ·134
Same as in Score Motor Assy AS ·2380 21
SURFERS.
page 50
Switch 8. Sracket A5SY AS 982 648
Br ack e
t ,
Switch
P 126 ·537
IMPORTANT
See New Style
Switching Componenb
Commencing
Page 107
DESCRIPTION
PART NO.
DESCRIPTION
PART NO.
Switch Plate (11 used) .. . P'137 -5
Switch Screw (2 per Switch Stack)
Appropriate Screw for each Stack
listed by reference to Stack .
listed from Motor end of Assy.
(1)
MS 540 50 ·110
(2)
MS ·540 ·26 ·11 0
(3)
MS ·540 ·32 110
(4) Same as in (3)
(5) Same as in (3)
(6) Same as In (3)
(7)
MS540 ·44110
(8)
_ MS5408110
(9) Same as in (2)
(10)
MS ·540 ·38110
(11) Same as in (8)
Shooter Gauge Sail
P·6359 ·5
Sid. Rails
Left ..
.
P 6360 30
Right.
A·2900 15
Slingshot Kicker, parts related to
Coil Assv . (3 used)
AS ·156614
Switch
&
Bracket Assv .
See Rebound Switch Assy .
Spot Lite Unit
See Stepping Units. full Reset
Stepping Unit. Continuous
Match (0-9) Unit
AS ·827 ·317
As illustrated.
page 114. with
Base Plate Assy
A·1768 ·25
Bracket
_
P·5052
Coil..... .. ..
.
E·184 252
Contact Plate (Wired)
W·l 034 ·9
Elastic Stop Nut ..
. .. _ M·319 ·3
FASTENERS
Order nuts. screws , etc .
by name or description
with reference to
(a) AS ·827 ·317 .
(b) Part which fastener secures
Grommet
R 111 ·29
Pivot Pin
S·73748
Plate. Switch
Flat
P 126 154
Spring
P·137 ·5
Plate . Switch Mounting
P·126 ·247
Plunger
S-496 ·100
Ratchet
&
Shaft
C·l 050
Spring. Extension
SP ·l00 125
Step·up Arm Assy
A-1765 ·24
Switch
SW -Ol0 ·203
Washer
Bell Mounting
P·801 -15
Wiper Assy
P·801 ·107
Wiper A.sy
AS -l046 -501
Stepping Units, full Reset
Ball Count Unit
AS ·827 ·332
A. illustrated.
page 115. with
Coil. Step -up
E·184 ·205
Contact Plate (Wifed)
W-l043 ·9
Core Plug Assy
A-613 -33
Elastic Stop Nut
M-319 ·3
Pivot Pin
S-737 -48
Plate Switch .
Flat (3 used)
P·126 ·154
Spring (2 used)
P·137 -5
Plate . Switch Mounting .. P·126·247
Ratchet
&
Shaft
C-l 050 · 7
Screw
Order by name or description
with reference to
(a) AS ·827 ·332
'bt
Part
which screw secures
Solder Lug
P 40514
Sprinu.
Ex tensf cn ,
Reset
_
SP·l00 -113
Step-up
SP·l00 ·113
Torsion
_
SP·370
Step ·up Arm Assy
A·1765 ·8
Swrtc n.
Closed at zero
SW 100467
End of stroke
SW -l 00 -472
Washer (Wiper)
P 801 ·107
Wiper Assy
AS 1046 ·552
Groovy Unit . . . . .
.
_ AS 827 322
Same as Ball Count Unit, excepting
Contact Plate (W ired)
W 1077 ·2
Pin (Ratchet)
M·740
Ratchet & Shaft
C·l 050 ·6·38
Screws
Order by name or description
with
reference to
(a) AS·827 ·332 .
(b) Part which Screw secures
Switch
Closed at top
SW -l00 -487
End of stroke
SW ·Ol0 ·203
Wiper A.sy
AS-l046-504
Spot Lite Unit .. _
AS·827 -318
Same as Ball Count Unit, excepting
Coil . Step'up
CO ·26GG ·9
Contact Plate (Wired)
W·l072 ·8
Pin (Ratchet)
M-740
Ratchet & Shaft
. _
C-l050 -9-41
Screws
Order by name or description
wi
th reference to
(a) AS-827 ·318
(b) Part which SCrew secures
Spring .
Extension.
Reset
SP ·l00 ·120
Step-up
SP·l00 ·113
Torsion
Sp·370
Step -up Arm Assy
A·1765 ·4
Switch
SW ·Ol0 -46
Wiper As.y
AS ·l046·525
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
61
