SPECIFIC PARTS DATA
Listed chronologically by games
MINI-ZAG
DESCRIPTION
PART
NO.
Alternator
AS -1900-101
See page 89
Back glass
Glass _
_. _. .
G ·33269
Plexiglas
_... ..
_...
M -1481-16
Ball Count Unit
See Stepping Units, Full Reset
Ball Gate Assy
See Gate
Ball Ejector Unit
Ball Return
_. . .. AS -42822
A. Illustrated. page 136
Playfield (2 used) __. _. .. AS -428 -24
As illustrated, page 136, excepting
Coil
_.. _. E·184-56
Ball Return Unit
See Ball Ejector Unit
Ball Return Guide .. .. _. .. P 6346-1
Ball Return Kicker
See Ball Ejector Unit
Ball Return Trough Assy . .
A -2896 3
Ball Shooter Gauge .. ...
__ P -6359-5
Button, Rollover
See Rollover Button
Counter
Ball
See Stepping Units, Full Reset
Replay
Same as in THE WIGGLER. Page 47
Score
Same as in CAPERSVILLE, page 43
Total Play. .
. .. _. _. .. E 130 10
Flipper
&
Pin Assy.
Same as in SURFERS. page 49
Flipper Zipper
Same as in ROCKET III. page 45
IMPORTANT: ALSO SEE PAGE 141
ALSO SEE :
Switch & Bracket Assy.,
Flipper Zipper
Free Ball Gate
SeeGate
Gate,
Ball
_ .
AS 1315 -4
See NOTES B, C, page 158
Free Ball
Above panel
___ M 1335·1
Below panel...
..
AS -1587 -62
Same asGate, Basin Street,
Swivel Type, OIXIELAND.
page 53
Gauge, Ball Shooter. _.. ___ P -6359 5
DESCRIPTION
PART
NO.
DESCRIPTION
PART
NO.
Groovy Unit
See Stepping Units, Full Reset
Guide, Ball Return. __ ..
Kickback Assy., Zagger
Bracket,
Coil
_ .
Mounting
.
Bumper, Plug
_
Coil_
_
.
Frame,
Kicker
.
Plunger
&
Striker Assy _..
Screw
Order
bv
name or description
with reference to
(al AS 2404 -1 ,
(b) Part which screw Secures
Spring. Compression. _. __ SP -200 175
P -6346-1
AS 2404-1
P-l08-53
P-6665-39
R -231-11
E-184235
P -6629-17
A -550 -5
Kicker
See Ball Ejector Unit
See Kickback Assy .,Zagger
See Slingshot Kicker
Lockdown, Panel, Playfield .. P 6784-5
Match Unit
See Stepping Unit, Continuous
Meter
See Counter, Total Play
Moveable Flippers
See Flipper Zipper
Plastic Shields (Set)
... _M 1330 -50
Playfield Panel Latch Rail
SeeSide Rail
Playfield Panel Lockdown _.. P -6784-5
Rails
SeeSide Rails
Rebound Switch Assy.
6 used
_ __. AS -982-509
6 used
_.. _.. _.
. _. AS ·982-561
Both illustrated, page 135
Relay, Interlock
See Relay, "KK" Type
8 Bank
Relay, "KK" Type
Single
HOLE KICKER
Coil
C·7800-332 -0
Frame
_
A ·604L·5
LEFT THUMPER BUMPER
Coil.
.. _
C·7800·334 ·0
Frame
A·604A-5
LOWER THUMPER BUMPER
Same as LEFT THUMPER BUMPER
RIGHT THUMPER BUMPER
Same as LEFT THUMPER BUMPER
LEFT REBOUND
Call .. ,
C·7800·341·0
Frame
A·604LD·5
RIGHT REBOUND
Same as LEFT REBOUND
4 Bank
1 POINT
Coil
C·7800-333
Frame
A·604LDP·5
10 POINT
Coil , Frame same as 1 POINT
100 POINT
Same as 10 POINT
RESET
Coil
C·7800·331
Frame
A·604L·5
8
Bank
WAYOUT NO _1
Coil _.........•... ..
C·7800 ·331
Frame
A·604L ·5
WAY OUT NO .2
Same asWAYOUT NO.1
TOP CENTER LANE
Coil
, . ,
C·7800 -3316
Frame
A·604LD·5
GAME aVE R (Interlock Relay)
Coil
Latch
,
C ·7BOO ·331
Trip
C·7800-334
Frame
Z·1154 -3
START (Interlock Relay)
Coils , Frame same as GAME aVE R
ORANGE MUSHROOM BUMPER
Coil, Frame same as TOP CENTER LANE
ADVANCE
Coil, Frame same as WAYOUT NO_ 1
FREE BALL
Coil ........ ....• ...
C·7BOO·341
Frame
A-604LD-5
15 Bank
1ST COIN CHUTE
Coil .... ... ....•...
C·7BOO ·331
Frame
_
A·604LP·5
2ND COIN CHUTE
Coil, Frame same as 1ST COIN CHUTE
3RD COIN CHUTE
Coil, Frame same as 1ST COIN CHUTE
ANTI·CHEAT
Coil
C·7800·3312
Frame
A·604L ·5
FEATURE
Coil ...... ........•.
C·7800 ·341
Frame
A·604LD·5
GROOVY
Coil
C·7BOO·3316
Frame
A·604LD·5
HOLD
Coil ....... ..•..•...
C·7800·332
Frame
A·604L·5
WHEN ORDERING PART, SPECifY PART NO. AND NAME Of GAME
60
