NUMERICAL PARTS LIST
P·6231.SERIES Retaining Ring (V) P·6629·26 Bracket, Insert (Back Cabinet)
P·6242· SERIES Backglass Retainer P·6629·27 Bracket, Retaining
P·6243·2 Latch (Back Glass Retainer) (Back Door, Single Player Garres)
P·6254 Bracket (Rollover SWitch) P·6629·36 Bracket, Support, Lower,
P·6254·1 " Orbit Unit AS-2380-34
P·6255.8 Unit Brace (Replay Counters) P·6629·46 Bracket, Support, Upper,
P·6256 Bracket, Stop, FI ipper Uni ts; Orbit Unit AS-2380-34
Swivel Type Free Ball Gates; P·6646·2 Panel Guide Lock
Target Kicker Assy. P·6647 Panel GUide, Left
P·6264 Handle (Mounting Board) P·6647-1 Panel GUide, Right
P·6264·1 Bracket, Lock Mounting, P·6665-5 Ball Return Trough
Score Motor Assys. P-6665-30 Switch Guard (Mystery Bonus)
P·6264·3 Bracket, Contact Plate, P·6665-39 Bracket, Mounting,
Orbiter Unit AS-2380-34 Kickback Assy. AS-2404
P·6264·4 Bracket, Motor Mounting, P-6665-47 Bracket, Latch-Locking Relay,
Spinner Motor Assy. AS-2386 Flipper Zipper Assy. AS-2397
P·6297·1 Cover, Coin Switch P-6665-53 Bracket, Latch-Lock: ng Relay,
P·6316·SERIES Retaining Ring (V) Flipper Zipper Assys. AS-2397·1, AS·2397·2
P·6344 Back Wall (Bali Trough), P·6665-62 Stop Bracket (Glass Frame Assy.)
(Automatic Ball Return) P-6694 Coin Guide
P·6346·1 Ball Return Guide See International Coin Mechanism Data,
P·6350·SERIES Coin Entry Plate commencing page 87
See International Coin Mechanism Data, P-6694-SERIES "
commencing page 81 P-6695 COin Guide (All Coins),
P·6359·SERIES Ball Shooter Gauge Coin Switch & Mounting Assy. AS-277·91
See Specific Parts Data P-6698 Plate, Side, Score Motor Assy.
for specific games, P-6698-1 "
commencing ROCKET III, page 45 P-6698·5 Side Plate, Front,
P·6360. SERIES Side Rail, (Playfield Panel Latch Rail) Orbit Uni t AS-2380-34
See Specific Parts Data for specific games, P·6698·7 Side Plate, Back
commencing MAD WORLD, page 16 Orbit Unit AS-2380-34
P·6363 Latch Lever (Front Moulding) P·6716 Cam, Actuator, Match Wheel Unit
P·6364·2 Bracket, Front Rai I P-6720 Support Bar Channel,
Front Rail Lock Assy. AS-2313-5 (Elevator Mounting Board)
P·6365·1 Latch, Front Rail P·6739 Ball GUide (Kickback Gate)
Front Rai I Lock Assy. AS-2313-5 P·6740 Br acket, Arch Extension,
P·6431·SERIES Coin Spacer Guide (Kickback Gate)
See International Coin Mechani sm Data, P·677 4 Guard, Motor,Spinner Motor Assy. AS·2386
commencing page 87 P-6784·SERIES Panel Lockdown
P·6442·13 Link, Ball Escape Assy. AS-2300-1 See Speci Ii c Parts Data
P·6495·26 Ball Guide for speci Ii c games,
P·6629·2 Bracket, Support, commencing THE WIGGLER, page 47
Score trotor Assys. P-6785 Bracket, Ball Guide (Kickback Gate)
P·6629·8 Bracket, Hinge Mounting, P-6785-3 Bracket, Guide (Kickback)
Score Motor Assys. P-6812 Latch, Right (Mounting Board)
p·6629-9 Support Channel, Back Cabinet P-6812-1 Latch, Left (Mounting Board).
P·6629·17 Frame, Kicker, P·6813 Latch, Score Counter Units
Kickback Assy. AS-2404 P·6815 Plate, Spacer (Mystery Bonus)
P·6629·25 Bracket, Retaining
(Back Door, Multiple Player Garnes) (V) See various components described in General Parts
Catalog, commencing page 82, and Specific Part.
Dota for specific games, commencing poge 8.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
