NUMERICAL PARTS LIST
P.310·14
Washer,
P-3389
Retaining Ring for 3/4 in. dia. shaft
Number Wheel & Hub Assy. AS-1565
P·3399·2
Button, HOLD
P.318·2
Bracket, Rebound Assy. AS-493-2
P-3473·2
Plate (Front Door Lock)
P.318-3
Bracket, Rebound Assy. AS-493-3
P·3656-1
Link Plate, Metal,
P.405·14
Solder Lug
Coil & Bracket Assys. (Thumper Bumper)
P.448
Snap Washer (V)
P·3656·2
Link Plate, Bakelite,
P.448·SERIES
"
Coil & Bracket Assys. (Thumper Bumper)
P.483
Speed Nut
P·3657
Bracket, Coil,
P.748·5
Bell, Gong Assy. AS-385-6
Coi I & Bracket Assys. (Thumper Bumper)
P·758·24
Lock Cam, Back Door
P-3658·3
Bracket, Mounting,
P·800-SERIES
Washer (V)
Coil & Bracket Assys. (Thumper Bumper)
P·801·SERIES
••
P·3662·6
Bracket, SIing-Stot Kicker Assys.
P.1l58.SERIES
Spring Washer (V)
P·3691-SERIES
Base Plate (V)
P.1365.SERIES
Cam, Cam Assys.,
P·3914
Leg Bolt Armor
Score Motor Assys.
P·4005·1
Lock Cam, Front Door
P.1376.1
Number Wheel,
P.4052·5
Leg
Number Wheel and Hub Assy. AS·1565
P.4491
Pawl, Hold (V)
P·1417·4.
Bracket, Number Wheel,
P·5022·1
Stop Plate
Replay Counters
P.5052
Bracket, Mounting (V)
P·1637· SERIES
Roll Pin (V)
P.5052·SERIES
"
P·1901
Washer, Rebound Assys.
P-5851
Holder, Switch Actuator,
P·1968·8
Support Bracket, Playfield Panel
Score Motor Assys.
P.1973·114
Link, Ball Escape Assy. AS-2300
P-5852
Switch Actuator, Score Motor Assys.
P·1973·160
Link, Flipper Zippers
P-5852·2
"
P.1973·168
Plate, Spinner Motor Assy. AS-2386
P-5867
Bracket (Gate or Barrier Wire)
P·2210·145
Plate, HOLD
P·5867-SERIES
"
P·2236·6
Bracket, Coi I,
P.5899
Cover, Rebound, Chrome
Bracket & Core Plug Assys.,
P·5899·SERIES
"
Trip Relay Resets
P.5900-1
Plate: Retaining (Ball Shooter)
P·2236-14
"
P·2239
Link,
P-5940·19
Front Door Trim, Top or Bottom
Reset Arm & Link Assys. AS-2373,
P·5940·20
Front Door Trim, Left
AS-2373-1
P·5940-21
Front Door Trim, RiRht
P·2451
Washer,
P-5946·17
Front Door Cover,
Number Wheel
&
Hub Assy. AS-1565
Triple Coin Chute Games
P·2768·9
Escutcheon Plate, HOLD Button
P·5946-20
Front Door, Cover
P·2768·26
Guide, Replay Button
Double Coin Chute Games
P·2879
Spring Cup,
P.5946-21
Front Door Cover,
Ball Shooter Assy. AS-2378
Single Coin Chute Games
P·2891·SERIES
Retaining Ring (V)
P-6000
Bracket, Swing Type Free Ball Gates
P·6000-1
"
P·2296·SERIES
Switch Cover (Page 12l)
P·3045-9
Lock Plate (Coin Box)
P·60 15·1
Bracket,
P·3089·35
Coin Box Cover
Gate Actuator Assys. AS-2308-4,
P·3089·38
"
AS·2308-8
P·6074.73
Coin Box Cover
P·3299-2
Button, HOLD 21
P-6074·82
"
P·3382
Pawl, Index, Stepping Units
P·6230
Back Door (V)
P·3384
Spring Stop, Stepping Units
P·6230·SERIES
"
P·3386
Stop Plate, Stepping Units
P·3387
Pawl, Escapement, Stepping Units
(V) See various components described in Generol Parts
Catalog,
commencing page 82, and Specific Parts
P·3387-1
"
Data for specific games, commencing page 8.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
170
