Page 128 - Bally 1969 Parts Catalog

SLING.SHOT KICKER ASSYS.I SEE NOTE A I
SW-100-403 __..
.---P-137-5
- MS540-8-11 0
P-126-471I
STUD
S-1784-2
ELASTIC
C- 342 STOPNUT SWITCH & BRACKET ASSEMBLY
GUIDE RING M-319-2 (AS-982-S09)
SWITCH & BRACKET ASSEMBLY
(AS-982-S61)
AS-982-5Gl is identical [0 AS-9H2-509, excepting
Switch is SW-IOO-503.
SWITCH ADJUSTMENT NOTE
When Sling-Shot Kicker is at re st , actuating blade of
Switch should just barely touch Rubber Ring, with
1/16 in. air-gap between switch points.
NOTE A
Sling-Shot Kicker Assy. (AS-1566-14) and related Switch & Bracket Assys. illustrated
above are used in ROCKET III.
Order Assys. and ports for earlier games* by name of part with reference to
(0) location of Sling-Shot Kicker Assy. and/or related Switch & Bracket Assy. and
(b) name of game.
Effective with ROCKET III and later games*, double check Specific Parts Data,
commencing with ROCKET III, page 45, under sub-heading: Sling-Shot Kicker.
'See chronological li.t of game., poge 7.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
