Page 127 - Bally 1969 Parts Catalog

BOUNCE-SWITCH
WS-S/16-S10
P-108-3
SW-010-144 0
C-583
SP-200-7
SPRING
(NOT VISIBLE)
5-739-8
P-2891-S CO-27R-ll
P-126-473
LAMPS SEE PAGE 162
LAMP-SOCKETS
E-120-25
E-120-33
J-Qd,
A-1653-1
E-120-81
E-120-99
SOUNDER ASSEMBLY
(AS-731-6)
A-14SS-1-~
Sounder Assembly is factory-adjusted to allow approxi-
mately 1/16 in. air-gap between bottom of Adjustment
Screw (MS-832-10-120) and top of Plunger, when Plung-
er is pulled all the way into coil. Increasing the air-
gap will increase the sound; decreasing the air-gap
will decrease the sound.
E-120-122
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
134
