FRONT CABINET
Front Door, Mounting Board, Playfield
(CONTINUED FROM PAGE 127)
Front Door
COIN HANDLING, PARTS RELATED TO
Coin Switch & Rejector Assy. *
See page 83
Coin Switch Cover* P-6297-1
Insulator
(Used with Coin Switch Cover) . P-150-78
Rubber Strip
(Used with Coin Entry Insert) .. R-221-33
Slug Rejector*
See International Coin Mechanism Data,
commencing page 87
Cover, Front Door
See Front Door Cover
Fasteners
Order fasteners (nuts, screws, washers, etc.)
by name or description with reference to (a)
port which fastener secures, (b) nome of game
Front Door (wood only)
Single Chute CA-567-166
Double Chutes CA-567-167
Triple Chutes ............• CA-567-168
Front Door Cover
Single Chute P-5946-20
Double Chute P-5946-21
Triple Chute P-5946-17
Hinge & Brocket Assy A-254-79
NOTE A
Order Coin Box, Coin Box Cov~r, Coin Box Divider
for CAPERSVILLE and earlier games by nome or
descript ion with reference to (a) name of game, (b)
single-coin or multiple coins.
For ROCKET III, order
Coin Box A-2790-25
Coin Box Cover P-3089-35
Coin Box Divider P-6074-73
For THE WIGGLER and later games*, order
Coin Box ...................•.............. A-2790-30
Coin Box Cover .................•......... P-3089-38
Coin Box Divider P-6074-82
• See chronological list of gomps, page 7.
Front Door
LOCK, PARTS RELA TED TO
Key
For obvious security reasons
Key is not separately sold
Key Hook* ...•.•......... M-389-1
Lock (with 2 Keys)* M-281-22
Lock Cam* .....•.•..•...• P-4005-1
Plate, Lock ............•.. P-3473-2
REPLAY BUTTON, PARTS RELATED TO
Button Assy •.••........•. A-1729-17
Button Guide* •............ P-2768-26
Retaining Ring .....••••.... P-2891-7
Switch* .....••....•...•• SW-100-358
Switch Plate
Flat. ......•.•........• P-126-155
Spring ....•...•........ P-137-5
Switch Protector Bracket* ..... P-6366-1
Washer .....•............ P-800-2
Tilt Switch & Bracket Assy .•..••• AS-982-258
Back-up Plate •••.••••••..• P-126-473
Bracket, Switch ...••......• P-126-29
Insulator .....•.•...•••••• P-150-77
Speed Nut .•••.....•....•. P-483
Switch .....•........ '.... SW-010-76
Switch Plate (Spring) •...••... P-137-5
(CONTINUED ON PAGE 129)
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
128
