e. To replace coil spring, remove "E" ring from kicker armature. (See Fig. Sa)
Compress kicker armature until square shaft can be removed from square hole. (See Fig. 5b)
With kicker armature removed, replace spring. (See Fig. 5c) Slide kicker armature back
through the round hole in coil mounting bracket and compress until square shaft can be re-
inserted into square hole. After re-inserting square shaft into square hole, compress just the
coil spring far enough back so that the "E" ring can be re-installed.
REMOVE
liE" RING
DIRECTION OF
COMPRESSION
•••
SLIDE SPRING
OFF TO REMOVE
Fig.
50
Fig.
5b
Fig. 5c
f. Reassemble kicker assembly and remount using the four (4) #8 ESNA nuts making sure coil
wire guard is re-inserted before nut is secured tight.
