Press the Escape button to return to the TestMenu. Press the Up button to display the next test, (or the
Downbutton to return to a previous test). Press the Enter button to activate that test.
1!9 All Lamps Test
Once the test name is shown under the Test Menu, press the Enter button. This test causes all the
controlled lamps to flash at the same time. Every controlled lamp should flash. Any other result
indicates the system has detected a problem.
Press the Escape button to return to the TestMenu. Press the Up button to display the next test, (or the
Downbutton to return to a previous test). Press the Enter button to activate that test.
1!
10.
Lampand
Flasher Test
Note:
The lights on the Helmet Assembly are NOT tested from the Lamp
&
Flasher 'lest.
See T. 15 - Helmet Light, to test the lights on the Helmet.
Once the test name is shown under the Test Menu, press the Enter button. This test causes all the
flashlamps and the controlled lamps to flash at the same time. The controlled lamps blink, while
the flashlamps cycle from highest to lowest. Any other result indicates the system has detected a
problem.
Press the Escape button to return to the TestMenu. Press the Up button to display the next test, (or the
Downbutton to return to a previous test). Press the Enter button to activate that test.
Press the Escape button to return to the Test Menu. Then, either press the Up or Down button to
return to a previous Test, or press the Escape button again to return to the Main Menu. Once in the
Main Menu, press the Up button to move to the next menu selection, the Utilities Menu, or press the
Down button to return to a previous Main Menu selection.
1!
11 Display Test
Once the test name is shown under the Test Menu, press the Enter button. This test allows you to
cycle through all of the display circuits. Each segment and digit should light in its turn. If a
segment or digit never lights, or stays lit all the time, the system has detected a problem. There are
two modes for testing the displays, Running and Stop.
Running -
This test cycles through several phases automatically. Each phase is designed to
test either an entire digit or a specific segment.
Press the Enter button at any time during the Running test mode and the test stops.
Use the Up or Downbuttons to cyclethrough each phase of the test manually.
Press the Enter button again to resume the Running test mode.
Stop-
ENTERING
A
HEAD
lEST lit POSSIBLE HEAD PROBLEMS
Upon entering any of the head tests (T.12,T.13, T.14) (except for T.16 Head Manual) for the first
time since entering diagnostics the head will rotate itself to the "home" position. A message will
be displayed telling you: "homing head please wait". The home position for the head is the first
face (mouth). Once the head has rotated to this face successfully the appropriate test will begin. If
the head can not "home" itself to the first face (mouth) then it will try to calibrate itself. A message
will be displayed telling you "calibrating head please wait". Calibrate re-times all the face
positions of the head, this may take up to a minute to complete. The calibrating will end with the
"home face" showing (mouth). Once the head has rotated ~ this face successfully the appropriate
THE MACHINE
