Press the Enter button to activate the Test Menu, once the menu name is shown under the Main
Menu. Then, use the Up or Down button to cycle through the Test Menu selections. Press the Enter
button to activate the desired test when that test appears in the displays.
T, TEST MENU
T.I
Switch Edges
T,2 Switch Levels
T.3 Single Switch
T.4 Solenoid Test
T.5 Flasher Test
T.6 General Illumination
T,7 Sound & Music Test
T.8 Single Lamps
T,9 All Lamps
T.IO Lamp & Flasher Tests
T,II
Display Test
T,I2 Thing Test
T.13 Bookcase Test
T.I
Switch Edges
For all switches, the number on the left indicates the column, the number on the right indicates the
row. Example-Switch 23 means 2nd column, 3rd row.
To test the Left and Right Flippers, press the Left or Right Flipper buttons during switch test. The
flipper name and switch number should show in the displays. Any other results indicate the system
has detected a problem with the flipper circuit.
To activate the Switch Edges Test, from the Test Menu, press the Enter button. The name and
number of each switch that is pressed is shown in the displays. If any other switch, or no switch at
all is indicated, the system has detected a problem with the switch circuit.
Press Escape to rerum to the Test Menu. Press the Up button to display the next test, (or the Down
button to rerum to a previous test). Press the Enter button to activate that test.
T.2 Switch Levels
Once the test name is shown under the Test Menu, press the Enter button. The name and number of
each switch that is activated is shown in the displays. This test automatically cycles through all
switches that are detected dosed. Current switch is indicated by a filled square.
Press the Escape button to return to the Test Menu. Press the Up button to display the next test, (or
the Down button to return to a previous test). Press the Enter button to activate that test.
The ADDAMS FAMILY 1-15
