5. Raise the hinged backbox upright and latch it into posicion. Unlock the backbox, and remove
the backglass, storing it carefully to avoid scratches. Remove the shipping block holding the
Insert Board. Unlatch and open the Insert Board. This allows access to the bolt holes used for
securing the backbox upright. Install the washer-head mounting bolts through the bottom holes
of the backbox into the threaded fasteners in the cabinet to secure the backbox. Close the Insert
Board and latch it in position. Reinstall the backglass, and lock the backbox.
6. Extend each leg leveler slightly below the leg bottom. so that all four foot pads are extended
about the same distance. Remove the cabinet from its support and place it on the floor.
7. Unlock and open the coin door. Locate the Molding Latch Lever. and move the lever toward
the left side of the game. to release the Front Molding. Lift the Front Molding off the
playfield cover glass return the Latch Lever toward the right. and close the coin door. Carefully
slide the glass downward. until it clears the grooves of the Left and Right Side Moldings. Lift
the glass up and away from the game. storing it carefully to avoid breakage.
8. Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for proper
playfield level (side-to-side) and playfield pitch angle (incline) of approximately 6-7 degrees.
NOTE: It is recommended that these measurements be made ON the playfleld, not the
cabinet nor the playfield cover glass. Tighten the nut on each leg leveler shaft to maintain this
setting. as shown in Figure 3.
CAUTION
Playfield pitch angle adjustments can affect the operation of the plumb bob tilt. inside the
cabinet. The plumb bob weight is among the parts in the cash box; the operator should install
the weight and adjust this tilt mechanism for proper operation, after completion of the desired
playfield pitch angle setting.
9. Move the game into the desired location; recheck the level and pitch angle of the playfield.
10. Verify that the
required number
of balls are installed in the game. THE ADDAMS FAMILY
uses 3 balls.
11. Install playfield mylars if desired.
NOTE:
THE ADDAMS FAMILY Diamond Plate™playfield does not require a protective
mylar. However. playfield mylars can be purchased thru your local Bally Distributor.
Specify part number 03-7960-20017-1 for full playfield mylar.
12. Clean and reinstall the playfield cover glass. reversing the procedure of step 7. Prepare the
game for player operation.
The ADDAMS FAMILY 1-3
