PINBALL GAME ASSEMBLY INSTRUCTIONS
THE ADDAMS FAMILY IS A 3 BALL GAME.
Weight: 290 Lbs.
Width: 26" Approx.
Length: 55" Approx.
Height: 85" Approx.
1. Open the shipping container; remove all cartons, parts, and other items, and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts
are provided among the parts in the cash box.
3. Attach the front legs (after installing leg levelers), using leg bolts See diagram below ..
Nut
,
",
4422-01117-00
\
See Detail View :
I
"
"
.....
Pinball Assembly, Playfield Pitch Angle, and Leg Leveler Details.
Detail View-
Leg Leveler
C·I0843-1
Leg
08·7377
Leg Leveler
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are free to move
(not kinked or pinched),
Be careful to avoid damaging wires at any stage of the assembly
process.
&.
CAUTION
FAILURE TO INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erecc. Always lower the
backbox forward onto the playfield cabinet on a layer of protective material to prevent marring
or damage and possible personal injury.
The ADDAMS FAMILY 1-2
