T.17 Right Under Divertor Test
This test checks the divertor that loads balls into the right
ball popper.
Press the Enter button and the right ball popper should kick a ball into the right gun assembly. At
the same time, the display should read, "Ball Should Go To Right Popper". If the ball is reloaded
into the popper, while still in Right Under Divertor test, it should kick out into the gun assembly
again. Any other resun for this test indicates a problem.
T.1
8 Clear Out Balls Test
The test checks the poppers and kickers that are under the
playfield.
Press the Enter button and all balls loaded into the poppers and troughs should be kicked out
until there are no balls in any under playfield location. At the same time, the display should read,
"Removing All Balls From Under Playfield". Any other results indicates a problem.
NOTE. As balls roll down the playfield and into the outhole, they will be continually kicked out of
the trough.
