T.7
Sound and Music Test
The Sound and Music Test checks the audio circuits.
This test has three modes for testing the sound and music circuits - Run, Repeat, and Stop.
Run
The Run mode steps through a sequence of sounds and music. Press
the Up or Down buttons during this portion of the Sound and Music test to advance to a
particular sound or tune without having to wait for the program to play all the sounds
available in the test. A sound or tune should be heard for each name and number that
appears in the display. Any other resuhs indicates the system has detected a problem..
Repeat
Press the Enter button at any time during the Run mode to cause the
program to stop and repeat a particular soundltune. The same sound should repeat
continuously until the Up or Down button is pressed. Any other results indicates the
system has detected a problem.
Stop
Press the Enter button at any time during the Repeat mode to stop this
test ahogether. Nothing should be heard. Any other results indicates the system has
detected a problem.
T.8
Single Lamp Test
The number assigned to each lamp indicates the lamp's postlon
in the matrix. The number on the left indicates the column. The number on the right indicates the
row. Example - Lamp 23 means 2nd column, 3rd row.
This test checks each lamp circuit individually. Press the Up or Down button to cycle through this
test. For each name and number that is shown in the display the corresponding lamp should light.
Any other results indicates the system has detected a problem.
T.9 All Lamps Test
This test causes all the controlled lamps to flash at the same time.
Every controlled lamp should flash. Any other results indicates the system has detected a
problem.
T.10 Lamp and Flasher Test
This test causes all the flash lamps and the controlled
lamps to flash at the same time. The controlled lamps blink, while the flash lamps cycle from
highest to lowest. Any other results indicates the system has detected a problem.
T.11 Display Test
This test automatically checks every dot in the Dot Matrix Display.
A series of patterns appear in sequence. Each pattern turns on and off a section of dots. Every
dot on the matrix display should be turned on and off during this test.
