Description
Lamp Boar'ds
(continued)
Lamp Board ("3-C'?
pin
C-13425
Part Number
5768-12597-00
24-8767
24-8768
5070-09054-00
5791-10871-05
Lamp Board
("3-
Til)
pin
C-12000
Description
Part Number
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Connector, 5-pin Sq post
5768-12245-00
24-8767
24-8768
5070-09054-00
5791-10871-05
Lamp Board ("3-L'?
pin
C-12709
Part Number
5768-12409-00
24-8767
24-8768
5070-09054-00
5791-10871-05
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Connector, 5-pin Sq post
Lamp Board ("3-R'?
pin
C-13361
Description
Part Number
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Connector, 5-pin Sq post
5768-12584-00
24-8767
24-8768
5070-09054-00
5791-10871-05
Lamp Board ("20
+
3
x "F'?
pin
C-13374
Part Number
5768-12591-00
24-8767
24-8768
5070-09054-00
5791-10871-12
Description
Part Number
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Connector, 12-pin Sq post
5768-12592-00
24-8803
24-8802
5791-10871-02
Lamp Board
("1'?
pin
8-12224
Part Number
5768-12312-00
24-8767
24-8768
5070-09054-00
Description
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4oo4, 1.0 A.
Connector, 5-pin Sq post
Lamp Board ("F'?
pin
C-13375
Description
Lamp PCB
Twist Lamp Socket
Bulb #906 (13V,O.69A.)
Connector, 2-pin Sq post
-,
Lamp Board ("B-D'?
pin
C-13537
Description
Lamp PCB
• Twi~t Lamp Socket
Bulb #555 (S.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
Connector, 11-pin Sq post
Description
Part Number
Lamp PCB
Twist Lamp Socket
Bulb #555 (6.3V, 0.25A.)
Diode, 1N4004, 1.0 A.
5768-12613-00
24-8767
24-8768
5070-09054-00
5791-10871-11
ROLLERGAMES 51
