8ackbox
Interconnect
Board
pin
0-12313-576
Part Number
5768-12332-00
5010-09534-00
5012-12238-00
5012-12337 -00
5012-10023-00
5012-12188-00
5490-10892-00
5731-09651-00
5733-12060-01
5791-10862-03
5791-10862-07
5791-10862-09
5791-10862-10
5791-10862-12
5791-10862-15
5791-10862-16
5791-10862-18
16-8850-291
Ckt Designator
W10 - W13
R14, R15
R13
R3,R4,R6
R1, R2, R5, R7-R9
U1 - U3
F1-F4
J2,J16
J9
J6
J7, J10, J20
J5,J18
J8
J4,J11,J12,J19
J1,J3,J14
Description
Master Interconnect PCB
Resistor, 00
Resistor, 3.3Kn, 5w, 10%
Resistor, 1.5Kn, 5w, 10%
Resistor, 40, 5w, 10%
Resistor, 30, 5w, 10%
Opto Isolator 4N25
Fuse, 5A.S.B., 250v
Fuse Holder, F1-F4
Connector, 3-pin Hdr Sq Pin
Connector, 7-pin Hdr Sq Pin
Connector, 9-pin Hdr Sq Pin
Connector, 10-pin Hdr Sq Pin
Connector, 12-pin Hdr Sq Pin
Connector, 15-pin Hdr Sq Pin
Connector, 16-pin Hdr Sq Pin
Connector, 18-pin Hdr Sq Pin
PCB Label
Lamp Boards
Backbox Relay Board
(Solenoid
10
&
11
Gen. Ilium)
pin
C-11998-1
Lamp Board ("5-L ")
pin
C-13362
Part Number
Description
Part Number
Description
5768-12243-00
Lamp PCB
5768-12585-00
Lamp PQB •
5070-09054-00
Diode, 1N4004, 1.0 A.
(01)
24-8767
Twist Lamp Socket
5580-09555-01
Relay, 24vdc, 30A.
(K1 )
24-8768
Bulb #555 (6.3V, 0.25A.)
5010-09534-00
Resistor DO
(W1, W2) 5070-09054-00
Diode, 1N4004, 1.0 A.
5791-12273-02
Header, 2-pin Sq post
(J1)
5791-10871-07
Connector, 7-pin Sq post
5791-12273-07
Header, 7-pin Sq post
(J2)
ROLLERGAMES 50
