GAME CONTROL LOCATIONS
Figure 2 shows the locations of the following switches, except for the last two (CPU and Sound Diagnostic
switches, which are shown in the Backbox portion of Figure 1, along the left edge of the CPU Board).
•
The Qn-Off switch is on the bottom 01 the cabinet near the right front leg.
The Volume Control is on the left inner wall of the cabinet on the tilt mechanisms board. It is accessible by
opening the coin box door.
The Credit switch is a pushbutton to the left of the coin door on the cabinet exterior.
GAME ADJUSTMENT/DIAGNOSTIC SWITCHES.
11l©I1.G©~
1F@1Fl©~
allows the operator to control all
game adjustments, obtain bookkeeping information, and diagnose problems, using only three switches
mounted on the inside of the coin door, along with the Credit button beside the coin door.
ADVANCE, AUTO-UP/MANUAl-DOWN,
and HIGH-SCORE RESET are the switches located on the
inside of the coin door. Refer to the text discussing Game Status Displays and the Test/Diagnostic
Procedures for details concerning button operation.
The Memory Protect switch is on the inside frame of the coin door. This interlock switch must be open to
clear bookkeeping totals and to make game adjustments.
It automatically opens, when the coin door
opens.
Figure 1 shows the locations of the two CPU Board switches (left edge 01CPU Board, Backbox View).
The CPU Diagnostic switch (SW 2) is the lower switch (of the two switches mounted on the lell edge of
the CPU Board) near a large, socketed microprocessor Chip. This switch initiates the Memory Chip Test
explained in the Test/Diagnostic Procedures.
The Sound Diagnostic switch (SW 1) is the upper switch of the two mounted on the left edge of the CPU
•
Board. This switch initiates the Sound Section Test. Refer to the Test/Diagnostic Procedures.
27-1111
Memory
Protect
Interlock
Swilch
A-S069
Volume & 47Q Resistor
Control
5010-10170-00
Assembly
8·6390 Front Molding
Molding Latch Lever, plo 0-9t 74·1
Plumb Bob Tilt Assembly:
01-3444
Upper Tilt Bracket
01-3445
Lower Tilt Bracket
12-6231
Wire Hanger
2O-6502-A
Plumb Bob Weight
4406-01120·00 Wingnut. #6-32
Game
Adjustment!
Diagnostic
Switches
/
/
5640-10932-00
On·OH
Switch
Figure 2, Pinball
Game Controls Locations
•
