13.
Install full playfield Mylar, if desired.
Note:
The
NO GOOD GOFERS
playfield is coated with a special hardcoat surface and does not
require a protective Mylar. However, mylars can be purchased through your local Williams
Distributor.
14.
Clean and reinstall the playfield cover glass. Replace and lock the front molding.
15. To attach the line cord, remove the four Phillips-head screws that mount to line cord cover plate to
the rear cabinet. Match the prongs on the plug with the holes in the receptacle, and push the line
cord securely into place. Make sure the cord is aligned with the indentation on the cover plate
(indentation should point toward bottom of the cabinet). Remount line cord cover plate. If desired,
four tamper resistant screws have been provided, in the unique parts bag, to remount cover plate.
(Part of cabinet shawn
for reference only)
~
Receptode
16.
Move the game into the desired location. Adjust the leg levelers so that the playfield pitch is the
recommended
6-1/2
degrees. This places the game in a FIXED position.
17.
If a padlock is desired, install the security bar as shown below.
Hasp
Hinge
Bracket
01-14085
Hasp Staple Bracket
01-14086
18.
IMPORTANT: Fill out and return the registration card.
1-5
