A-17223
16-0pto PCB & Bracket Assembly
Part Number
Designator
Description
A-16898.1
16-0pto Dual Mount PCB Assy.
•
5043-08996-00
ct
-CS
Capacitor, O.lIJF, 50v(±20%) Axial
5040-13102-00 C6
Capacitor, 470(.JF, @3Sv (±20%)
5791-13830-10 Jl-J4
Connector, 10-pin Header STR Sq.
5791-10862-13 J5
Connector, 13-pin Header STR Sq.
5671-13732-00 LEDl
Display LED Red
501 0-12928-00 R 1-R4, R23-R30,
Resistor, 270Q, 2w, 5%
R47-RSO
501 0-09999-00 RS-R12, R15-R22,
Resistor, 2K!l,
lf4w, 5%
A31-R46
501 0-0877 4-00 R13, R14, R51
Resistor, 22K!l, 1/4w, SOlo
5010-09162-00 R52, RS4, RS6,
Resistor, 1001<11,
1/4w, 5%
SO10-09034-00 R53, RS5
Resistor, 10Ka,
1/4w, 5%
5010-10631-00 RS?
Resistor, 1.2KQ, 1/2w, 5%
5370-12272-00 Ul-U5
IC LM339 Quad Compo
5070-09054-00 D1 - D19
Diode lN4004 1.0A.
01-20756
PCB Mounting Bracket
07 -6688-18N
Rivet 3/16 x
1/8"
Nickel
2-12
