MAGNET ASSEMBLIES
1) Remove Left Wire Ramp and Ramp Assembly #1.
2) Remove two hex head screws on the desired Opto Mounting Bracket.
3) Slide the Opto Mounting Bracket forward, until the assembly clears the back panel.
4)
Lift the magnet off of the bracket.
When replacing magnet, be sure the thermal breaker faces the rear of the game.
The thermal
breaker is located in the bulging part of the magnet. It
is a
sensor that detects if the magnet gets to
hot, and cuts it off if
it
does.
HEX HEAD
SCREWS
F~OM
RAMP ASSEMaL Y
#
1
SLOT FROM
RAMP
ASSEMBLY
#1
SLOT
FROM
RAMP
ASSEMBLY
#2
HEX
HEAD
SCREWS HOLDING
LEFT OPTO MOUNTING
BRACKET
FRONT VIEW
